Operating Instructions blueplanet 1502xi/2502xi
The installation instructions for authorized electri-
cians begin after the operating instructions
For the operator
Operating Instructions
blueplanet 1502xi / 2502xi
General Notes ..........................................................4
1
About This Documentation ........................................4
1.1 Retention of documents . ............................................4
1.2 Symbols used in this document ..................................4
1.3 Name plate ...............................................................4
2
Safety Instructions and Regulations ..........................4
3
Notes on Installation and Operation . ..........................5
3.1 Intended use .............................................................5
3.2 Factory warranty and liability . ....................................6
3.3 Service ......................................................................6
4
Operation . .................................................................6
4.1 Overview of controls and displays ..............................6
4.2 LED displays ..............................................................7
4.4 Level 1 menu - Display mode ....................................8
4.5 Level 2 menu - Configuration mode ..........................9
4.6 DC switch . ...............................................................10
4.7 Night time start switch ............................................10
4.8 The RS485 interface ................................................10
4.9 Display ....................................................................10
5
Accessories..............................................................13
6
Troubleshooting . ......................................................14
7
Recycling and Disposal ............................................16
Page
Advertisement
Table of Contents
Related Manuals for Kaco blueplanet 1502xi
Summary of Contents for Kaco blueplanet 1502xi
-
Page 1: Table Of Contents
The installation instructions for authorized electri- cians begin after the operating instructions For the operator Operating Instructions blueplanet 1502xi / 2502xi General Notes ............4 About This Documentation ........4 1.1 Retention of documents ..........4 1.2 Symbols used in this document ........4 1.3 Name plate ...............4 Safety Instructions and Regulations ......4 Notes on Installation and Operation ......5 3.1 Intended use .............5 3.2 Factory warranty and liability ........6 3.3 Service ..............6... -
Page 2: General Notes
Even when the unit is disconnected, high contact – CAUTION indicates a hazardous situation which, voltages may still be present within the unit. if not avoided, could result in minor or moderate injury. Page Operating Instructions blueplanet 1502xi/2502xi... -
Page 3: Notes On Installation And Operation
If necessary, your solar installer or KACO new energy GmbH will The inverter may only be operated with a permanent connec- assist you. Damage reports must be received by the shipping tion to the public power grid. company in writing within six days of receipt of the goods. The inverter is not intended for mobile use. When transporting the inverter, the original or equivalent pack- Any other or additional use is not considered the intended use. aging is to be used, as this ensures safe transport. The manufacturer/supplier is not liable for damage caused by such unintended use. Damage caused by such unintended use is at the sole risk of the operator. Intended use also includes adherence to the operating and installation instructions. Your authorized electrician undertakes the registration with your power supply company and obtains approval for your photovoltaic installation from the supply grid operator on your behalf. Some of the documents that you require in order to register your photovoltaic installation and have it approved are included in the installation instructions. Page 5 Operating Instructions blueplanet 1502xi/2502xi... -
Page 4: Factory Warranty And Liability
LED displays Display of the operating state However, despite all quality assurance measures, faults may Control keys occur in exceptional cases. In such cases, KACO new energy S witch between displays and configuration of parameters GmbH will provide you with the maximum possible support. AC/DC switch KACO new energy GmbH will make every effort to remedy Disconnects AC and DC power from the inverter such faults in an expeditious manner and without a great deal Night time start switch of bureaucracy. Contact our service department directly by F or activating the display after nightfall telephone at + 1 866 522 6765. GFDI fuse Ground Fault Detector Interruptor Fuse. -
Page 5: Led Displays
LED () (red): at the last entry in a menu, the first entry is displayed again The LED indicates that the grid-feed was stopped due to a the next time key “1” is pressed (see Figure 4.4). fault. Wait approx. 10 minutes to see if the fault is only temporary in nature. If this is not the case, notify your authorized electri- cian. I MPOR TANT If there is a power failure on the public grid, LED (3) does not light up. If this happens, all LEDs and the display go out. The inverter is shut down completely. The inverter can only resume its normal operation when the public utility grid is available again. Check whether the fault in question relates to a general power failure or whether the circuit breaker between the utility service and the inverter has tripped. If the circuit breaker has tripped, notify your authorized technician. If there was a power failure, simply wait until the fault has been cleared. The system auto- matically re-starts. Page Operating Instructions blueplanet 1502xi/2502xi... -
Page 6: Level 1 Menu - Display Mode
Figure 4.4: Display mode menu “Clear yield”. Operating hours today Today’s hours of operation. As soon as the inverter is in stand- by mode (i.e. when LED (1) lights up), the running time is added Total operating hours The hours of operation since installation of the inverter. As soon as the inverter is in stand-by mode (i.e. when LED (1) lights up), the running time is added up. Page Operating Instructions blueplanet 1502xi/2502xi... -
Page 7: Level 2 Menu - Configuration Mode
Current country setting by pressing key “1”. By pressing key “2”, the address can be set in a consecutive manner from 1 to 32. The address then jumps back to 1. The RS485 interface is used Language selection to communicate with the KACO proLOG, watchDOG or other monitor. If several inverters are connected to a KACO proLOG, watchDOG or other monitor each address may Clear the grid-feed counter only be used once. It is possible to monitor 32 blueplanet inverters with one KACO proLOG. To connect the RS485 interface, please contact your installer. -
Page 8: Dc Switch
The daily yield, daily hours of Due to measuring tolerances, the measured values may operation and the max. daily grid-feed power are available not always correspond to the actual values. The inverter’s until the following morning and are cleared when PV generator measuring elements have been selected to ensure maximum voltage is present again. solar yields. Due to these tolerances, the daily yields displayed on the inverter may deviate from the values on your supply grid operator’s grid-feed counter by up to 15%. At low power operation the sensors within the unit are not as accurate as when at higher power therefore long term operation may cause this high deviation. Under normal operating conditions this deviation is minimal. Page 10 Operating Instructions blueplanet 1502xi/2502xi... - Page 9 The line relay and the shutdown of the power electronics are tested prior to the commencement of grid-feed mode. Power limitation If the generator is producing too much power, the inverter limits to the max. power. This can occur in the midday hours if the generator has been too largely dimensioned. This is not a malfunction. Waiting time after a fault After a fault, the inverter waits a defined country-specific amount of time before it switches on (Installation Instructions, section 4, Technical Data). Table 4.1: Explanation of the operating states Fault signals When these error messages are displayed, the grid-feed is interrupted, the red LED (3) lights up, and the fault signal relay has switched. This error correction takes a country-specific length of time (see Installation Instructions, section 3, Technical Data). Afterwards the red Page 11 Operating Instructions blueplanet 1502xi/2502xi...
- Page 10 Line failure The line frequency is too low. This error can be grid-related. Underfrequency Line failure The line frequency is too high. This error can be grid-related. Overfrequency Failure An error occurred during charging of the DC link. Notify your authorized electri- DC Link cian. Failure An internal error occurred during the calculation algorithm. Try to restart or notify your algorithm authorized electrician. Overtemperature The temperature is too high. To avoid damage, the grid-feed was stopped. Provide for controlling unit sufficient ventilation. Table 4.2: Fault signals Page 12 Operating Instructions blueplanet 1502xi/2502xi...
-
Page 11: Accessories
You can access your PV data at: www.kaco-newenergy.com/blueplanetweblogin.php KACO-proLOG Are you looking for professional monitoring and data logging equipment? The KACO-proLOG is the high-end solution for your PV installation. Error messages by SMS (text message), fax or e-mail, remote access to the installation, the presenta- tion of the PV installation on the Internet and much more are no problem whatsoever for the KACO-proLOG. Up to 32 inverters can be connected to the KACO-proLOG via the RS485 interface. Figure 5.2: KACO-watchDOG installation Information about additional accessories can be found in our general catalogue. Figure 5.1: KACO-proLOG KACO-watchDOG The KACO-watchDOG card is the integrated communication option from KACO for monitoring your PV installation. Up to... -
Page 12: Troubleshooting
(more than 10 times per day). For an explanation of the individual display error texts, please see the fault signals. Page 1 Operating Instructions blueplanet 1502xi/2502xi... - Page 13 Details pertaining to the photovoltaic module Details pertaining to the inverter – Module type, manufacturer (if available, also send the – The unit’s serial number data sheet) – Model – The number of modules in series – A short description of the error – The number of strings – Is the error reproducible? If yes, how? – Generator power – Does the error occur sporadically? – Describe the prevailing insolation conditions when the error occurred? – Time of day Page 15 Operating Instructions blueplanet 1502xi/2502xi...
-
Page 14: Recycling And Disposal
KACO does it’s best to ensure our vendors follow a low carbon manufacturing process as we do ourselves. It is not always possible but if you have questions about our products or the components in our products don’t hesitate to call +1 (866) 522-6765.and ask. Device Do not dispose of faulty inverters or accessories together with household waste. Ensure that the old unit and, where applica- ble, any accessories are disposed of in a proper manner. Most areas have public electronic waste disposal and/or recycling plants. Feel free to contact KACO at +1 (866) 522-6765 to request information about e-waste recycling in your area. Packaging Ensure that the transport packaging is recycled. Page 1 Operating Instructions blueplanet 1502xi/2502xi...
