6.7.4 Rotate Engraving & Cutting
On the Common Params Settings page, move cursor to【Rotate Engraving
& Cutting】and press【Enter】. Press【↑】 【↓】to move cursor, press
【 ← 】 【 → 】 to modify options and press number keys to modify
parameters, press【Enter】to save settings.
Name
Rotary
Rotary Axis
Pulse Count Per
Rotate
WWW.SZTROCEN.COM
Fiugre6-7-8 Rotate Engraving & Cutting Interface
Table6-7-4 Rotate Engraving & Cutting Instruction
Instruction
Enable or Disable rotary engraving function.
The axis which rotary engraving uses.
The pulse parameters for the motor to make the rotary axis
rotate one circle.
