1.6.2.2 Port of Panel and Wiring Board
Connect panel and wiring board with CN1 and CN2 cables.
Name Introduction
CN1 Connect CN1 port of panel and wiring board with CN1 cable.
CN2 Connect CN2 port of panel and wiring board with CN2 cable.
1.6.2.3 Signal Input
There are two groups of signal input ports.
PIN Name
1 DC24V
2 IN1
3 IN2
11.IN
4 IN3
5 IN4
6 GND
WWW.SZTROCEN.COM
Table1-6-2 Port of Panel and Wiring Board
Table1-6-3 Wiring Board Signal Input Port Instruction
Instruction
Output DC voltage (24V)
Door open protection signal (This function needs to be
turned on in the panel to be effective).
Foot switch (This function needs to be turned on in the
panel to be effective).
Reserved
Reserved
Power ground
