Trocen AWC708C Plus User Manual page 75

Config】 ) and set 【 AutoFocus Distance】 here to keep the distance between
laser head and working table.
Name
Auto Focus Distance
(mm)
Key Move Speed
(mm/s)
Run Box Speed
(mm/s)
Cut Box Speed
WWW.SZTROCEN.COM
Fiugre6-7-6 Common Parameters Interface
Table6-7-2 Common Parameters Instruction
Instruction
The distance between the laser head and working
platform.
The motion speed of axis when press the direction keys on
panel.
The speed at which the laser head runs along the outer
frame of graphics without laser output.
The speed at which the laser head cuts along the outer
AWC708C PLUS Motion Control User Manual
74
