Name
Panel and
mainboard
Wiring Board
USB Cable (3m)
Network Cable
(5m)
CN1 (1.6m)
CN2 (1.6m)
8 PIN (1m)
WWW.SZTROCEN.COM
Table1-3-1 Wire Introduction
Appearance
The panel (mainboard) of AWC708C PLUS.
The wiring board of AWC708C PLUS.
Connect computer and panel by USB.
Connect computer and panel by network.
Connect the CN1 port of main board and
panel.
Connect the CN2 port of main board and
panel.
Patch cord with USB and network port.
AWC708C PLUS Motion Control User Manual
