3) On the Jog Control page, move cursor to【Z Jog】, then press
direction key (【←】/【→】) one time to make the laser heads
move a jog distance on the X direction. Then press【Laser】and
mark the laser head2 position with B.
4) Measure the distance between A and B, then input the value into
【Actual Length】.
5) On the main page, press 【Stop】 + 【Shift】 at the same time to open
the Manufacture Params Settings page. Then move cursor to 【Axis
Parameters】option and press【Enter】. Then open the Z Axis
Parameters page and move cursor to【Distance Per Pulse】, press
【Enter】. Input 200mm into【Expected Length】and input the
distance between A and B into 【 Actual Length】 . Then press 【 Enter】 ,
the distance per pulse of Z axis will be calculated.
6) When multi-head cutting, the calculation of distance per pulse of
U/V/W is the same as Z axis. Mark the position of laser head3 to
calculate the distance per pulse of V axis. Mark the position of laser
head4 to calculate the distance per pulse of W axis.
When the pulse distance value of any axis is close to or less than 1, the
pulse distance can't be adjusted and is always 1. Users need to adjust pulse
of motor driver first, then measure the distance per pulse again. The
recommended pulse distance value is 5 or more.
