Enable the function, if the graphics beyond the working range, the laser
head will automatically adjust position to cut the graphics perfectly. After
adjustment, if the graphics still beyond the border, the system prompts
"Beyond border limit! Continue?", press【Enter】key to continue to cut,
part of the graphics beyond border limit will not be cut, as shown in Figure
6-7-3/6-7-4. Press【ESC】to cancel operation.
As shown in Figure 6-7-5, the green graphics is beyond the current working
range. If enable the function【Auto Origin (Beyond border limit)】, the
machine will automatically move to the position of the red graphics for
cutting. If the graphics is still beyond the border after re-positioning or
disable the function, the machine will only cut part of the graphics which
is within the working range like Figure 6-7-4.
