flat, smooth work surface with the flanged mixing fins facing upright. Align one Drum Segment B
Tumbler Drum Assembly
Tumbler Drum Assembly
along one side of Segment A, matching up the holes in the fins.
B. Fasten Segment A to first Segment B using:
at each of the five holes. Hand tighten all bolts.
C. Attach the other Segment B to the other side of
D. Using the slotted screwdriver and
g
A. Place the endcap, name plate down, on work
surface. Note position of the screen on the endcap.
Carefully pick up the 3 sectioned partially assembled
drum from Step 1 and by bending it with the mixing
fins on the inside, fit it into the rim of the endcap,
forming three-quarters of the cylinder. Be careful to
locate the center panel (Segment A) adjacent to the
screen and fit the mixing fins on both sides of this
segment into the alignment slots of the endcap.
STEP 1:
Initial Drum
Body Assembly
1 Drum Segment A (item 12)
g
2 Drum Segments B (item 13)
g
10 #10 Bolts (silver) (item 22)
g
10 #10 Flat Washers (item 23)
g
10 #10 Lock Washers (item 24)
g
10 #10-32 Hex Nuts (item 25)
g
A. Place Drum Segment A on a
1 #10 Bolt (silver)
1 #10 Flat Washer
1 #10 Lock Washer
1 #10 Hex Nut
Segment A the same way.
3
tighten all the fasteners.
STEP 2:

Drum Assembly

1 Endcap (item 14)
g
1 Drum Body Assembly (from Step 1)
Select:
/ " wrench,
8
Select:
7
