OWNER'S MANUAL, ASSEMBLY
and SAFETY INSTRUCTIONS
for Gasoline Hedge Trimmer Attachment
Single Edge
Gasoline
Hedge Trimmer
Attachment
Shown with Mantis Tiller engine attached.
AND
Double Edge
Gasoline
Hedge Trimmer
Attachment
Shown with Mantis Tiller engine attached.
©2009,
MANTIS
Division Schiller Grounds Care, Inc.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Mantis 2224DAHM
Summary of Contents for Mantis 2224DAHM
- Page 1 ® OWNER’S MANUAL, ASSEMBLY and SAFETY INSTRUCTIONS for Gasoline Hedge Trimmer Attachment Single Edge Gasoline Hedge Trimmer Attachment Shown with Mantis Tiller engine attached. Double Edge Gasoline Hedge Trimmer Attachment Shown with Mantis Tiller engine attached. ©2009, MANTIS Division Schiller Grounds Care, Inc.
-
Page 2: Table Of Contents
NTRODUCTION I. I Page MPORTANT NFORMATION On behalf of everyone at Mantis we would A. Introduction ..........2 like to thank you for your purchase of a B. Special Safety Information ....2 Mantis Gasoline Powered Hedge Trimmer. C. Fuel Safety Information......3 II. -
Page 3: Fuel Safety Information
C. Fuel Safety Information WARNING DANGER HANDLE FUEL WITH CARE, IT IS HIGHLY FLAMMABLE. FUELING A HOT ENGINE OR NEAR AN IGNITION SOURCE CAN CAUSE A FIRE AND RESULT IN SERIOUS PERSONAL INJURY AND/ OR PROPERTY DAMAGE. Don’t fuel, refuel or check fuel while smoking or Always pull starter cord slowly until resistance is near an open flame or other ignition source. -
Page 4: Safety Decals
It is your responsibility to replace the decals when they become hard to read. The part numbers for ordering decals are in Section B, Safety Decal Identification (shown at bottom of this page). The location of these decals is illustrated below. MANTIS LABEL Single Edge Gasoline P/N 487 MA... -
Page 5: General Safety Rules
Keep a good footing at all Have repairs made by a qualified dealer or times. repairman. See that only original Mantis Don’t ever grasp cutting blades for any reason. parts are used. Don’t attempt to clear cut material while Don’t operate the machine with a damaged or... -
Page 6: Warnings - Do's
I I m m p p o o r r t t a a n n t t : : Always follow the Engine and Fuel Warnings found in your Tiller Manual. If you don’t have your Tiller Manual, call our Customer Service Department at 1-800-366-6268 to purchase a replacement or visit www.mantis.com to download a copy. -
Page 7: Assembly Instructions
MANTIS DEALER. ware bag from their boxes. The hardware bag consists of the following items: To remove the engine from your Mantis Description tiller you will need to identify which throttle cable connection you have. There are two dif- 1/4-20 Lock Nut ferent styles. - Page 8 Detach the throttle cable at the carburetor by loosening the two 10mm nuts on the thread- ed end Throttle Cable 10mm nuts engine. Slide the engine over the 1” diameter stem containing the hex drive on the gear Swivel housing until it is seated all the way down on the gear housing (see illustration below).
-
Page 9: Operation
IV OPERATION WARNING DANGER THE OPERATOR OF THIS HEDGE TRIMMER IS RESPONSIBLE FOR ACCIDENTS OR HAZARDS OCCURRING TO HIMSELF, OTHER PEOPLE OR THEIR PROPERTY. CHECK YOUR TILLER MANUAL FOR PROPER OPERATING INSTRUCTIONS FOR THE ENGINE TOPPING TARTING NGINE RIMMER NGINE RIMMER TTACHMENT TTACHMENT... -
Page 10: Maintenance
TRIMMING proceed to cut. Use overlapping sweeping motions away from your body to achieve a safe and even cut. WARNING DANGER 6 6 . . These units are designed to BLADES COAST AFTER RELEASING THROTTLE OR STOPPING ENGINE. cut any type of hedge or shrub;... -
Page 11: Long Term Storage (Over 60 Days)
O PURCHASE A service found in this manual. REPLACEMENT R VISIT WWW MANTIS COM TO DOWNLOAD A COPY OF THIS MANUAL 5 5 . . Drain the fuel tank and pull the starter rope several times to remove the fuel from... -
Page 12: Blade Adjustment
LADE DJUSTMENT Single Edge Trimmer WARNING DANGER SWITCH OFF THE ENGINE BEFORE LUBRICATING OR ADJUSTING THE BLADES The care and adjustment of the blades is most important to the efficient operation of the trimmer and especially to the long life of the engine. - Page 13 CUTTING BAR AND SIDE HANDLE ASSEMBLY Single Edge Trimmers...
- Page 14 REAR HANDLE ASSEMBLY Single Edge Trimmers...
- Page 15 CUTTING BAR ASSEMBLY Double Edge Trimmers...
- Page 16 HANDLE ASSEMBLY Double Edge Trimmers...
