GE C2K Hardware Reference Manual page 91

GPIO De-bounce Enable Register
The GPIO De-bounce Enable Register enables a de-bounce circuit to be applied to any GPIO line
designated as an input to filter relays, switches, and contacts. The circuit waits for 15ms of
glitch-free input signal before registering a change-of-state in the Data Register.
Address offset: 0x38
Access: Read/write
Bits Field
15 GPIO15_DEBOUNCE_EN
14 GPIO14_DEBOUNCE_EN
13 GPIO13_DEBOUNCE_EN
12 GPIO12_DEBOUNCE_EN
11 GPIO11_DEBOUNCE_EN
10 GPIO10_DEBOUNCE_EN
9 GPIO9_DEBOUNCE_EN
8 GPIO8_DEBOUNCE_EN
5-25
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Default
0 GPIO15 Debounce Enable—enables a debounce circuit
for GPIO15 line if designated as an input in the Control
Register.
0 = disable de-bounce circuit
1 = enable de-bounce circuit
0 GPIO14 Debounce Enable—enables a debounce circuit
for GPIO14 line if designated as an input in the Control
Register.
0 = disable de-bounce circuit
1 = enable de-bounce circuit
0 GPIO13 Debounce Enable—enables a debounce circuit
for GPIO13 line if designated as an input in the Control
Register.
0 = disable de-bounce circuit
1 = enable de-bounce circuit
0 GPIO12 Debounce Enable—enables a debounce circuit
for GPIO12 line if designated as an input in the Control
Register.
0 = disable de-bounce circuit
1 = enable de-bounce circuit
0 GPIO11 Debounce Enable—enables a debounce circuit
for GPIO11 line if designated as an input in the Control
Register.
0 = disable de-bounce circuit
1 = enable de-bounce circuit
0 GPIO10 Debounce Enable—enables a debounce circuit
for GPIO10 line if designated as an input in the Control
Register.
0 = disable de-bounce circuit
1 = enable de-bounce circuit
0 GPIO9 Debounce Enable—enables a debounce circuit
for GPIO9 line if designated as an input in the Control
Register.
0 = disable de-bounce circuit
1 = enable de-bounce circuit
0 GPIO8 Debounce Enable—enables a debounce circuit
for GPIO8 line if designated as an input in the Control
Register.
0 = disable de-bounce circuit
1 = enable de-bounce circuit
Resources
Description
C2K User's Guide
