Operating Instruction for VarioCAM®
8 Menu structural VarioCAM®

Menu structural VarioCAM

8
After powering on (pressing the C-button) and brief initialisation, the camera is in live mode. The menu
®
structure of VarioCAM
®
chapter 11 IRBIS remote Software
8.1

Live-Mode

In Live-Mode, a temperature bar is displayed, which allocates the object temperatures to the colour
representation of the thermal picture. The active temperature range (minimum and maximum
temperature) is represented with the temperature bar.
The colour palettes can be changed by pressing the C-button. The VarioCAM-Palette is the default.
Using the joystick, the thermal picture with respect to
temperature level
temperature range
can be optimised.
Fig. 24 Live Mode
Pressing Enter changes to Focus Mode (see Focus Mode 8.2
A long press of the T-button opens the Spot-Editor.
Operating Instructions
can be controled by VarioCAM
page 72).
- ¯
¬ ®
© InfraTec GmbH 2007
®
®
itself as well as by software IRBIS
page 20).
®
remote (see
19
