Operating Instruction for VarioCAM®

4 Unpacking and Checking

Unpacking and Checking
4
On receipt of the VarioCAM
The supplier must be informed immediately of any damage.
®
The VarioCAM system is delivered in an equipment case or in transport packaging.
The basic package contains the following components:
®
VarioCAM camera with LW IR 1.0/25 lens and integrated digital video camera and
3.8" TFT display (professional equipment)
Li-ION battery NP-QM91D (Sony) with fast charging function
AC-SQ950 battery charger
Compact Flash card
Lens protective cover
Shoulder strap
®
VarioCAM instruction manual
Transport case
Optional accessories
FRIWO MPP 30 (15 V DC) mains adapter with 6-pole LEMO connector
LW IR 1.0/12.5 wide angle lens
LW IR 1.0/50 telephoto lens
Breakout box, 14-pole camera cable.
Headset
FireWire (IEEE 1394) PCI card
FireWire (IEEE 1394) 6-pole cable.
Equipment stand
In addition, 2 macro lenses (2x, 6x) for the IR lens LW IR 1.0/25 are available. More details about these
are available on request.
Operating Instructions
®
please check for completeness and that the components are not damaged.
© InfraTec GmbH 2007 9
