3.3
Technical Data
Spectral range
Temperature measurement range
Temperature resolution @ 30 °C
Measurement accuracy
Emissivity
Recording process/image format (pixels)
Detector
IR-image frequency
Standard telephoto lens, FOV, IFOV, min. focus
Standard lens, FOV, IFOV, min. focus
Close-up lens 1 on standard lens, FOV, IFOV
Close-up lens 2 on standard lens, FOV, IFOV
Standard wide angle lens, FOV, IFOV, min. focus
Zoom function
A/D conversion
Image storage
Language recording/text commentary
Real-time storage
Analogue interfaces
Interfaces
Integrated digital video camera
Power supply
Battery system
Operating time with battery
Working temperature range
Storage temperature range
Humidity during operation and storage
Dimensions (complete equipment)
Weight (complete equipment)
Tripod connection
Display
Seeker
Controls
Automatic functions
Display functions
Measurement functions
Protection class in operation
Shock resistance
Vibration resistance in operation
8
(7.5 ... 14) µm
(-40 ... 1.200) °C, optional > 2.000 °C
better than 0.1 K
±2 K, ±2 %
adjustable from 0.1 to 1.0 in steps of 0.01
Focal Plane Array (320 x 240)
patented uncooled microbolometer array
50/60 Hz
50 mm, (16 x 12)°, 0.9 mrad, 2 m
25 mm, (32 x 25)°, 1.8 mrad, 0.5 m
0.17 x, (87 x 66) mm, 149 mm
0.5 x, (28 x 22) mm, 50 mm
12.5 mm, (64 x 50)°, 3.6 mrad, 0.2 m
up to 4.2 times, digital, infinitely variable
16 Bit
CF card, optional FireWire (IEEE 1394)
image-integrated
Optional internal storage up to 873 images
PAL/NTSC-FBAS and S-Video, headset
RS232, optional FireWire (IEEE 1394)
(640 x 480) pixels, colour
Li-Ion battery, mains adapter, optional FireWire
(IEEE 1394)
Li-Ion, fast recharge, mains and optional
car charger unit
ca. 3 h with standard battery
(-15 ... 50)°C
(-40 .. 70)°C
relative humidity 10 % to 95 %, not precipitating
(235 x 185 x 110) mm
ca. 2,2 kg
1/4" screw thread
daylight viewable, digital
3.8"-Active Colour-TFT-display
integrated high-resolution colour TFT seeker
4 keys, joystick with 5 functions
Autofocus, Autoimage, Autolevel, Image Storage
Thermogram, operator guidance, menu, results,
status
freely-selectable ROI, Auto-Hot-/Cold-Spot-display,
isotherms
IP 54, IEC 529
25G, IEC 68-2-29
2G, IEC 68-2-6
© InfraTec GmbH 2007
Operating Instruction for VarioCAM®
3 Technical Description
