- Page 1 BLG-BC1 Series Operating Instructions (Rev 1.1 4/25/17) Corporate Headquarters: 1080 North 11th Street, San Jose, CA 95112 Phone: (408) 292-2214 Fax: (408) 292-2733 www.mountztorque.com...
- Page 2 BLG-BC1 Series Operating Instructions Name of Parts BLG-4000BC1 (Lever Start type) BLG-5000BC1 (Lever or Push Start) Selectable by the Switch Two-way Start System (Switchable between Lever Start and Push-to-Start) Power tool cable Power tool cable Marking between “Lever” and “Push” start selection.
- Page 3 BLG-BC1 Series Operating Instructions Operating the BLG-4000BC1 Model 1. Attach power tool cable to the BLG-4000 screwdriver and the transformer. Make sure notch at the cable end aligns with the notch on the driver connector. Tighten knurled ground ring. 2. Plug in power cord to the back of the transformer and power outlet. Flip power switch to “ON” position located on the front of transformer.
- Page 4 BLG-BC1 Series Operating Instructions Screw Counter Display Screw Count Display Section/Set Value Display F2 Button Section: Function Display Section F1 Button In the normal mode, the screw fastening count set value is Screw Count/Function displayed first. After starting the count, the remaining Mode Display screw fastening count is displayed.
- Page 5 BLG-BC1 Series Operating Instructions Other Operations The count is to be returned to the default value during Pressing the F3 button for 2 seconds or more, resets the screw fastening operation. the screw fastening count value. How to check the Screw Counter Timer: set time...
- Page 6 BLG-BC1 Series Operating Instructions List of Function Settings (continued) Display Setting Function Symbol Setting Description <Default Value> System Setting Each Buzzer or Reverse Count Enable/Disable is set up. The setting is performed with a combination of the tenth digit and single unit digit.
- Page 7 BLG-BC1 Series Operating Instructions Operation Changing to the Setting Mode: Press the F1 button for more than 2 seconds in the normal mode. Then “P” will be displayed in the function display section and the mode will be changed to the setting mode.
- Page 8 BLG-BC1 Series Operating Instructions Operation Changing to the Normal Mode: Press the F1 button for more than 2 seconds in the setting mode. Then the mode will be changed to the normal mode and the value set for the count will be displayed.
- Page 9 BLG-BC1 Series Operating Instructions Torque Reference Charts These charts are meant to be used as guidelines for setting the torque on the BLG-BC1 Series electric screwdrivers. The drivers have a torque adjustment scale showing reference numbers. These numbers determine the approximate torque setting.
- Page 10 1. The BLG-BC1 Series screwdrivers are a precision torque control instrument and should be handled with care at all times. 2. Only use the transformers listed in the Mountz catalog or website for appropriate BLG-BC1 Series driver model (If you have any questions regarding the appropriate transformer set-up, contact Mountz Customer Service Department).
