- Page 1 BLG-Series Operating Instructions Rev 1.0 (5/13/13) Corporate Headquarters: 1080 North 11th Street, San Jose, CA 95112 Phone: (408) 292-2214 Fax: (408) 292-2733 www.mountztorque.com...
- Page 2 BLG-Series Operating Instructions Name of Parts BLG-4000 (lever start BLG-5000 (Lever or Push Start) Selectable by the Switch Two-way Start System (Switchable between Lever Start and Push-to-Start) Power tool cable Power tool cable Marking between “Lever” and “Push”start selection. Hanger...
- Page 3 BLG-Series Operating Instructions Operating the BLG-4000 Model 1. Attach power tool cable to the BLG-4000 screwdriver and the transformer. Make sure notch in plug lines up with the notch on the socket. Tighten knurled ground ring. 2. Plug in power cord to the back of the transformer and power outlet. Flip power switch to “ON” position located on the front of transformer.
- Page 4 How to Read the Torque Charts Torque ranges (lbf.in) approximate tightening torque, operated with no load at maximum speed. Verify torque setting with a torque testing system. lbf.in lbf.in BLG-4000 BLG-5000 R (Red) S (Silver) Torque Range 1.8 - 4.8 lbf.in Torque Range 1.7 - 10 lbf.in...
- Page 5 1. The BLG-Series screwdrivers are a precision torque control instrument and should be handled with care at all times. 2. Only use the transformers listed in the Mountz catalog or website for appropriate BLG-Series driver model (If you have any questions regarding the appropriate transformer set-up, contact Mountz Customer Service Department).
