- Page 1 BF-Series (BF060, BF080 & BF120 models) Operation Instructions Rev 2.2 (4/13/17) for V3 Models Only Page 1 Corporate Headquarters: 1080 North 11th Street, San Jose, CA 95112 Phone: (408) 292-2214 Fax: (408) 292-2733 www.mountztorque.com...
- Page 2 BF-Series (BF060, BF080 & BF120 models) Operation Instructions Introduction - Various models that range from 0.17 - 10.4 lbf.in - High performance Swiss Maxon brushless motor design provides durability and reduces the standard maintenance costs for electric screwdrivers. - Designed for high production environments. Minimal heat build-up even when tool is operated continuously.
- Page 3 BF-Series (BF060, BF080 & BF120 models) Operation Instructions General Operation for BF-Series models 1. Attach power tool cable to the BF-Series screwdriver and the transformer. Make sure notch at the cable end aligns with the notch on the driver connector. Tighten knurled ground ring.
- Page 4 Program Lock Key The Program Lock Key protects from incidental or operator tampering of the programmable settings on the side of select BF-Series models* (V3 models only). To adjust the settings the Program Lock Key must be is plugged into the STC40 &...
- Page 5 BF-Series (BF060, BF080 & BF120 models) Operation Instructions BF-Series Standard Models & Soft Stop Models (continued) How to Adjust Soft Start Setting There are 3 different time settings for the Soft Start mode which are (0.2, 0.4 & 0.6 seconds). The default setting is OFF.
- Page 6 BF-Series (BF060, BF080 & BF120 models) Operation Instructions BF-Series Standard Plus Models & Soft Stop Plus Models The “Plus” models feature a selectable Double Hit Mode for soft joint applications and a selectable Soft Start mode (from 0.2, 0.4 & 0.6 seconds). This option is only available with Standard &...
- Page 7 BF-Series (BF060, BF080 & BF120 models) Operation Instructions BF-Series Angle Control & Auto Reverse models Set the start and stop point by angle control within a range of 0.25 - 15 turns. Also set the “Stop Holding Time” within a range of 0.1 to 6 seconds.
- Page 8 BF-Series (BF060, BF080 & BF120 models) Operation Instructions Operating BF-Series Angle Control & Auto Reverse models Angle Setting for the first RUN 1. Keep the first Run button pressed for over 2 seconds for angle setting. Then press first Run button one by one for the desired rotating angle.
- Page 9 BF-Series (BF060, BF080 & BF120 models) Operation Instructions Time Setting for STOP & HOLD 1. Keep the stop time button pressed over 2 seconds. Then click the stop time button one by one for desired stop holding time. 2. Select the R position of F/R switch for increasing set time or F position for decreasing set time.
- Page 10 BF-Series (BF060, BF080 & BF120 models) Operation Instructions Angle Setting for the reverse RUN 1. Keep the both first Run & stop time buttons pressed over 2 seconds for unlock. Then click stop time button one by one for the desired angle 2.
- Page 11 BF-Series (BF060, BF080 & BF120 models) Operation Instructions Page 11 Corporate Headquarters: 1080 North 11th Street, San Jose, CA 95112 Phone: (408) 292-2214 Fax: (408) 292-2733 www.mountztorque.com...
- Page 12 Models and Soft Stop Models. RPM & Soft Start Settings cannot be adjusted without it. The program Key cannot be used with BF-Series Standard Plus Models, Soft Stop Plus Models & Angle & Auto Reverse Models. Accessories Pistol Grip Attachment The Pistol Grip attachment is an accessory item that converts the BF-Series in- line electric screwdrivers into pistol grip style tools.
- Page 13 Torque Cover For: BF060, BF080 & BF120 models Item # 145611 Protects the BF-Series tools from incidental or operator tampering of torque setting. Torque Arms The EZ-Glider torque arms are designed to improve production and quality control during the assembly process.
- Page 14 BF-Series (BF060, BF080 & BF120 models) Operation Instructions Torque Charts These charts are meant to be used as guidelines for setting the torque on the BF-Series electric screwdrivers. The drivers have a torque scale on the torque adjustment nut showing reference numbers. These numbers determine the approximate torque setting.
- Page 15 BF-Series (BF060, BF080 & BF120 models) Operation Instructions Torque Charts (Continued) lbf.in lbf.in BF120 & BFT120 BFS120 K (Black) K (Black) Torque Range 2-10.4 lbf.in Torque Range 2-9.1lbf.in G (Gold) G (Gold) Torque Range Torque Range 1.7-3 lbf.in 1.7-3 lbf.in...
- Page 16 1. The BF-Series screwdrivers are a precision torque control instrument and should be handled with care at all times. 2. Only use the transformers listed in the Mountz catalog or website for appropriate BF-Series driver model (If you have any questions regarding the appropriate transformer set-up, contact Mountz Customer Service Department).
