Singer Instruments ROTOR HDA User Manual page 21

software icon guiDe
IcOn nAME SETTIng
repeat Liquid
Target
Pinning
dry Mix On/Off
Target
Target Agar
Mixing
clearance
Target Agar
Mixing
diameter
Target Agar
Mixing
cycles
wet Mix On/Off
Target
Target Liquid
Mixing
diameter
Target Liquid
Mixing
speed
Target Liquid
Mixing
cycles
Target Liquid
Mixing
Travel
Pad Pickup
Pressure
DEScrIPTIOn
The number of times each target pin-
ning will repeat.
Agar mixing can be used to ensure that
a good contact with the target media is
established. Agar mixing prints multiple
times at a specified radius around the
target spot on the agar after the initial
central print has been established.
The distance the Pad Head retracts
from the agar surface at each stage of
the mix.
The diameter of the mix. Using step-in
reduces the diameter from the specified
diameter uniformly with each cycle for a
thorough mix.
The number of cycles (comprising of 5
steps) that the dry mix on source plates
will be executed.
Liquid mixing can be used to ensure
thorough depositing of cells in the liquid
solution. Liquid mixing uses either a
circular or helical movement.
The diameter of the mix applied to both
the x and y axis. Using step-in reduces
the diameter from the specified diam-
eter uniformly with each cycle for a
thorough mix.
The speed at which wet mixes are car-
ried out.
The number of cycles the mix will
include.
The distance that the Pad Head retracts
on 3d mixes.
The pressure applied by the Pad Head
when picking up pads.
TAb UnIT
Target >Pinning integer
Target >dry Mix Boolean
Target >dry Mix mm
Target >dry Mix mm
Target >dry Mix integer
Target >wet Mix Boolean
Target >wet Mix mm
Target >wet Mix mm/s
Target >wet Mix Times
Target >wet Mix mm
Pads %
singerinstruments.com
MIn MAx DEFAUlT
1 10 1
Off On Off
0 4 0.5
0.1 2 1
1 10 1
Off On Off
1 3 1
1 25 25
1 10 1
0.25 15 3
0 100 80
21
