Singer Instruments ROTOR HDA User Manual page 20

software icon guiDe
IcOn nAME SETTIng
wet Mix On/Off
source
source
Mixing
diameter
source
Mixing
speed
source
Mixing
cycles
source
Mixing
Travel
Permanent
offset
Target
Pinning
Pressure
Target Agar
Pinning
speed
Target Agar
Pinning
Overshoot
repeat Agar
Target
Pinning
Target Liquid
Pinning
speed
Target Liquid
Pinning
Backoff
20
DEScrIPTIOn
Liquid mixing can be used to invigorate
the cells in a liquid solution. Liquid
mixing uses either a circular or helical
movement.
The diameter of the mix applied to both
the x and y axis.
The speed at which wet mixes are car-
ried out.
The number of cycles the mix will
include.
The distance that the Pad Head retracts
on 3d mixes.
A permanent offset can be specified
to reset the nominal centre for each
source pinning. This feature is useful
when pinning from source plates that
have been printed to a non-central
location.
The pressure that the Pad Head will use
to push onto the agar.
The speed that the Pad Head will use to
connect to the agar surface.
The amount of travel that will be applied
after connection to the agar surface has
been made.
The number of times each target pin-
ning will repeat.
The speed applied to pinning to wet
source plates.
The retraction distance applied to the
Pad Head after connection to the bot-
tom of the plate.
TAb UnIT
source>wet Mix Boolean
source>wet Mix mm
source>wet Mix mm/s
source>wet Mix integer
source>wet Mix mm
source>Permanent Point
Offset
Target>Pinning %
Target>Pinning mm/s
Target>Pinning mm
Target>Pinning integer
Target >Pinning mm/s
Target >Pinning mm
MIn MAx DEFAUlT
Off On Off
1 3 1
1 25 25
1 10 1
0.25 15 3
-3,-3 3,3 0,0
0 100 Varies for
each pad
1 20 19
2
speed speed
dependant dependant
1 10 1
1 19 19
-0.5 3 0.5
