software overview

1
·
This is the ROTOR Home Menu. From here you can
choose to run pre-existing programs or create your
own programs. in this example, we click Select And
Run Stored Programs.
·
NOTe: Follow the same 4 steps to select for an existing
program:
1. choose the type of source Plates.
2. choose the type of Target Plates.
3. choose the type of Pin Pads.
4. select required Program.
These four steps are demonstrated below.
2
·
select your Source Plates. They are the plates that
already have the desired strains on. The source could
be colonies grown on solid agar, or cultures grown in
liquid media. in solid agar, the rOTOr HdA currently
supports colony density up to 24576. in liquid media,
the rOTOr HdA supports multi-well plates at 96 and
384-density.
·
in this example we select 96 Agar.
3
·
select your Target Plates. They are the plates that
you want your desired strains to grow on. The types
of target plates available are only those compatible
with your previous selection. since we've selected our
source plate as 96 Agar, we won't be able to choose
the target plate density beyond 1536.
·
in this example we select 96 Agar.
·
NOTe: The rOTOr software will not allow you to
make a mistake during plate and rePad™ selection.
