PROTECT YOUR MODEL, YOURSELF
& OTHERS... FOLLOW THESE
IMPORTANT SAFETY PRECAUTIONS
1. Your Sequence ARF should not be considered a toy, but
rather a sophisticated, working model that functions very
much like a full-size airplane. Because of its performance
capabilities, the Sequence ARF, if not assembled and
operated correctly, could possibly cause injury to yourself or
spectators and damage to property.
2. You must assemble the model according to the
instructions. Do not alter or modify the model, as doing
so may result in an unsafe or unfl yable model. In a few
cases the instructions may differ slightly from the photos.
In those instances the written instructions should be
considered as correct.
3. You must take time to build straight, true and strong.
4. You must use an R/C radio system that is in fi rst-class
condition, and a correctly sized motor and components
throughout the building process.
5. You must correctly install all R/C and other components
so that the model operates correctly on the ground and in
the air.
6. You must check the operation of the model before every
fl ight to insure that all equipment is operating and that the
model has remained structurally sound. Be sure to check
clevises or other connectors often and replace them if they
show any signs of wear or fatigue.
7. If you are not an experienced pilot or have not fl own
this type of model before, we recommend that you get the
assistance of an experienced pilot in your R/C club for
your fi rst fl ights. If you're not a member of a club, your local
hobby shop has information about clubs in your area whose
membership includes experienced pilots.
8. While this kit has been fl ight tested to exceed normal use,
if the plane will be used for extremely high stress fl ying, such
as racing, or if a motor larger than one in the recommended
range is used, the modeler is responsible for taking steps to
reinforce the high stress points and/or substituting hardware
more suitable for the increased stress.
9. WARNING: The cowl and wheel pants included in this kit
are made of fi berglass, the fi bers of which may cause eye,
skin and respiratory tract irritation. Never blow into a part
to remove fi berglass dust, as the dust will blow back into
your eyes. Always wear safety goggles, a particle mask and
rubber gloves when grinding, drilling and sanding fi berglass
parts. Vacuum the parts and the work area thoroughly after
working with fi berglass parts.
We, as the kit manufacturer, provide you with a top quality,
thoroughly tested kit and instructions, but ultimately the
quality and fl yability of your fi nished model depends
on how you build it; therefore, we cannot in any way
guarantee the performance of your completed model,
and no representations are expressed or implied as to the
performance or safety of your completed model.
Remember: Take your time and follow the instructions to
end up with a well-built model that is straight and true.
DECISIONS YOU MUST MAKE
This is a partial list of items required to fi nish the Sequence
ARF that may require planning or decision making
before starting to build. Order numbers are provided in
parentheses.
Radio Equipment
The Sequence ARF requires a minimum 4-channel radio
system with four micro servos such as the Futaba
micro precision servo. For optimum performance, we
recommend using Futaba S3150 digital micro servos.
In addition, two 12" [305mm] servo extensions are required
for the aileron servos. Two 24" [610mm] servo extensions
are required for the elevator and rudder servos if installing
the servos in the optional aft location. Servo extensions will
not be required for the elevator and rudder servos if using the
recommended power system and battery. If you are using
a radio system that does not support mixing functions, a
Y-harness will also be required to connect the aileron servos
to the receiver. One 6" [152mm] servo extension is required
for the ESC.
❏
Futaba S3115 Micro Precision Servo (FUTM0415)
OR
❏
Futaba S3150 Slim Digital Servo (FUTM0303)
Plus
❏
Hobbico
®
Extension 12" [152mm]
Futaba J (HCAM2100)
❏
Futaba Dual Servo Extension 6" J (FUTM4130)
❏
Hobbico Servo Extension 24" Futaba J (HCAM2200)
❏
Hobbico Extension 6" Futaba J (HCAM2000)
Motor Recommendation
The recommended motor for the Sequence ARF is a
RimFire
™
.32 (42-50-800) brushless outrunner motor.
❏
Great Planes RimFire .32 (42-50-800) Out-Runner
Brushless (GPMG4700)
3
®
S3115
