2.6.10

SATA Signal Connector

Pin
1
2
3
4
5
6
7
2.6.11

COM 1/2/3/4/5/6

Pin
1
2
3
4
5
6
Chapter 2 – Hardware Information
Pin 1
Pin name
GND
SATA_TX+
SATA_TX-
GND
SATA_RX-
SATA_RX+
GND
RS-232
DCD
RXD
TXD
DTR
GND
DSR
Pin 7
Signal Type
GND
DIFF
DIFF
GND
DIFF
DIFF
GND
RS-422
TX-
TX+
RX+
RX-
NC
NC
Signal Level
-
-
-
-
-
-
-
RS-485
DATA-
DATA+
NC
NC
NC
NC
19
