2.6.1 VGA Port

Pin
Signal
1
Red
3
Blue
5
GND
7
GND
9
VGA_VCC
11
NC
13
VGA_HSYNC
15
DDC_CLK

2.6.2 DC-IN

Pin
Signal
1
PWR_IN
3
NC

2.6.3 HDMI Port

Pin
Signal
1
HDMI_DATA2_P
3
HDMI_DATA2_N
5
GND
7
HDMI_DATA0_P
9
HDMI_DATA0_N
Chapter 2 – Hardware Information
Pin
Signal
2
Green
4
NC
6
GND
8
GND
10
GND
12
DDC_DATA
14
VGA_VSYNC
Signal
Pin
2
GND
Signal
Pin
2
GND
4
HDMI_DATA1_P
6
HDMI_DATA1_N
8
GND
10
HDMI_CLK_P
14
