Wonderfire Gasflame 3 639 GFC Installer's Manual

Convector box
Hide thumbs
Table of Contents

Advertisement

Quick Links

Convector Box
THIS APPLIANCE IS FOR USE WITH NATURAL GAS (G20)
WHEN CONVERTED USING CONVERSION KIT NO. 0591301 THIS
APPLIANCE IS FOR USE WITH PROPANE GAS (G31)
THIS APPLIANCE IS FOR USE IN THE UNITED KINGDOM (GB) AND
THE REPUBLIC OF IRELAND (IE) ONLY.
We trust that these instructions give sufficient details to enable this appliance to
be installed and maintained satisfactorily. However, if further information is
required, our Wonderfire Technical Helpline will be pleased to help.
INSTALLER: Please leave this guide with the owner
© Wonderfire
INSTALLER'S GUIDE
Gasflame 3
MODEL 639 GFC
Inset Decorative
Gas Fire
(G.C No. 32-815-81)
Please telephone 08706 061 065
3003043/01
