Related Manuals for Cooke & Lewis CLDH-14
Summary of Contents for Cooke & Lewis CLDH-14
- Page 1 90 cm Downdraft Chimney Hood GB IE 90 cm Downdraft Chimney Hood - Barcode: 5052931258819 WARNING: Read the instructions before using the appliance. WHTD90CL-C&L-A5 GB-IM-06.indd 1 11/20/13 10:03 AM...
- Page 2 Warning This appliance is intended only to be used with an electric hob. DO NOT use this appliance with a gas hob WHTD90CL-C&L-A5 GB-IM-06.indd 2 11/20/13 10:03 AM...
- Page 3 [01] x 1 [02] x 1 [03] x 4 [04] x 2 [05] x 1 1 : 1 [06] x 8 (3.5 x 16mm) [07] x 12 (3.5 x 9.5mm) WHTD90CL 90 cm Downdraft Chimney Hood WHTD90CL-C&L-A5 GB-IM-06.indd 3 11/20/13 10:03 AM...
-
Page 4: Table Of Contents
Let's get started... These instructions are for your safety. Please read through them thoroughly before use and retain them for future reference. Getting started… Your product Before you start Safety more detail… Operation Care and maintenance Troubleshooting Recycling and disposal Technical and legal information Guarantee CE Declaration of conformity... -
Page 5: Getting Started
Your product WHTD90CL 90 cm Downdraft Chimney Hood Before you start Your product Installation guide located at the end of the guidebook Things to check before you start To avoid the risks that are always present when you use an electrical appliance it is important that this cooker hood is installed correctly and that you read the safety instructions carefully to avoid misuse and hazards. -
Page 6: Safety
Before you start WHTD90CL 90 cm Downdraft Chimney Hood Safety Accessories not supplied Ø150mm SELF ADHESIVE VENT PACK 2 (UK & IE) ALUMINIUM TAPE Safety These instructions are for your safety. Please read through them thoroughly prior to installation and retain them for future reference. •... - Page 7 Safety WHTD90CL 90 cm Downdraft Chimney Hood Accessible parts may become hot during use. Young children should be kept away. Care should be taken to avoid touching the appliance The Manufacturer highly recommends that this appliance be kept out of the reach of babies and small children.
- Page 8 Safety WHTD90CL 90 cm Downdraft Chimney Hood Regularly check the power plug and power cord for damage. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Do not allow the electric cables to touch the hot parts of the appliance.
- Page 9 Safety WHTD90CL 90 cm Downdraft Chimney Hood The appliance is not intended to be operated by means of external timer or separated remote-control system. The appliance is for domestic use only. Warning: Consult local regulations regarding fumes outlets. Do not connect the hood to that room ventilation is appropriate with the local authorities.
- Page 10 Safety WHTD90CL 90 cm Downdraft Chimney Hood Warning: The hood may stop working during an electrostatic discharge (e.g. lightning). This involves no risk of damage. Switch off the electricity supply to the hood and reconnect after one minute. Warning: This appliance is not intended to be used with gas hobs.
-
Page 11: In More Detail
Operation WHTD90CL 90 cm Downdraft Chimney Hood Product functions • This appliance extracts the air of the kitchen to remove the odours and keep an optimum level of the air quality inside the room, it also allows you to illuminate the cooking area. Switching on/off •... -
Page 12: Care And Maintenance
Care and maintenance WHTD90CL 90 cm Downdraft Chimney Hood Aluminium filter replacement Aluminium filters: Use non-corrosive, liquid detergent or a stainless steel cleaner. 1 MONTH MAX. 65˚C Aluminium filters: to avoid fires, clean thoroughly once a month. To do so, remove the filters and wash with hot water and detergent. -
Page 13: Troubleshooting
Troubleshooting WHTD90CL 90 cm Downdraft Chimney Hood Troubleshooting Fault Cause Solution Hood doesn’t No power supply. Check the plug. work. Check the main switch. Poor airflow. Aluminum grease filters Clean the filters. See Care and are dirty. maintenance section. Motor running, Butterfly valve jammed. -
Page 14: Recycling And Disposal
Recycling and disposal WHTD90CL 90 cm Downdraft Chimney Hood Technical and legal information Recycling and disposal Environmental protection Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice. - Page 15 Technical and legal information WHTD90CL 90 cm Downdraft Chimney Hood Wiring All installation work must be carried out by a competent person or qualified electrician. Before connecting the mains supply ensure that the mains voltage corresponds to the voltage on the rating plate. WARNING: THIS APPLIANCE MUST BE EARTHED.
- Page 16 Technical and legal information WHTD90CL 90 cm Downdraft Chimney Hood Technical and legal information The Manufacturer declines all liability for damage caused to persons and objects due to incorrect or improper installation of the appliance. Electrical Requirements Any permanent electrical installation must comply with the latest I.E.E. regulations and local electricity company regulations.
-
Page 17: Guarantee
Guarantee WHTD90CL 90 cm Downdraft Chimney Hood Guarantee This appliance is covered by a full manufacturer’s 2 year parts and 2 year labour guarantee and covers all parts and labour costs associated with the repair of the appliance in a domestic environment. We will repair any defect that arises due to faulty materials or workmanship and use genuine manufacturers parts. - Page 18 Guarantee WHTD90CL 90 cm Downdraft Chimney Hood Guarantee Exclusions to the guarantee This guarantee does NOT cover: Appliances that have been damaged or neglected as a result of failure to store, assemble, install, use or care of the products in accordance with the manufacturer’s instructions - GAA will not accept responsibility under this guarantee if a product is damaged or becomes defective due to, misuse, neglect, wilful or accidental damage or act of god.
-
Page 19: Ce Declaration Of Conformity
CE Declaration of Conformity WHTD90CL 90 cm Downdraft Chimney Hood CE Declaration of Conformity MANUFACTURER: CATA C/ Ter nº 2, Torelló 08570 - Barcelona (Spain) ADDRESS: We hereby certify that the mentioned accessory complies with the essential requirements of the European Directives applicable, including their modifications and the corresponding transpositions from the national law. -
Page 20: Installation
Installation DUCTED OPTION VENT PACK 2 (UK + IE) You can only choose the ducted option as the type of installation. Mark and cut a hole in the worktop using the dimensions shown above. WHTD90CL-C&L-A5 GB-IM-06.indd 20 11/20/13 10:03 AM... - Page 21 Unscrew the 8 screws fixing the wind chamber and put it aside. [01] [01] x 1 Insert the hood body [01] into cabinet slowly. WHTD90CL-C&L-A5 GB-IM-06.indd 21 11/20/13 10:03 AM...
- Page 22 [03] x 4 [07] Fig1 [07] x 8 [03] Fig2 Remove the eight screws shown in Fig. 1, then re-insert the eight screws into the bracket [03] and 8 screws provided [07] into the side of the hood as shown in Fig. 2. Important: Do not need to fix the top two bracket if the cabinet is not wood based.
- Page 23 Fix the wind chamber back using the 8 previously removed screws. [02] [07] [02] x 1 [07] x 4 Fix the power box [02] using 4 screws [07] and connect the wire accordingly. WHTD90CL-C&L-A5 GB-IM-06.indd 23 11/20/13 10:03 AM...
- Page 24 Vent Pack 2 (UK + IE) Fix the vent pack 2 using self adhesive aluminium tape. [05] x 1 [05] Plug in the cooker hood and fix the decorative glass [05]. WHTD90CL-C&L-A5 GB-IM-06.indd 24 11/20/13 10:03 AM...
- Page 25 WHTD90CL-C&L-A5 GB-IM-06.indd 25 11/20/13 10:03 AM...
- Page 26 WHTD90CL-C&L-A5 GB-IM-06.indd 26 11/20/13 10:03 AM...
- Page 27 WHTD90CL-C&L-A5 GB-IM-06.indd 27 11/20/13 10:03 AM...
- Page 28 B&Q plc, Chandlers Ford, Hants, SO53 3LE United Kingdom www.diy.com WHTD90CL-C&L-A5 GB-IM-06.indd 28 11/20/13 10:03 AM...
