TriBrer AOP100 User Manual

Handheld measuring instrument. optical power meter. optical laser source. optical multi meter
Hide thumbs
Table of Contents

Advertisement

Quick Links

TriBrer
Handheld measuring instrument
R R
USER'S GUIDE
Optical power meter
Optical laser source
Optical multi meter
English
English
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AOP100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TriBrer AOP100

Summary of Contents for TriBrer AOP100

  • Page 1 TriBrer USER'S GUIDE Handheld measuring instrument Optical power meter English Optical laser source English Optical multi meter English...
  • Page 3 USER'S GUIDE Handheld measuring instrument Optical power meter English Optical laser source English Optical multi meter English...

  • Page 5: Optical Power Meter

    USER'S GUIDE Optical Power Meter English...

  • Page 6: Precautions For Use

    WARNING Any undefined change or modification of this manual will deprive you of the right to operate the equipment. To reduce the risk of fire or electric shock, do not expose the equipment to rain or humidity. To prevent electric shock, please do not open the shell, and it must be repaired by qualified personnel.
  • Page 7 Standard Optical Power Meter >2s PERM Save Unit Host FC/SC Adapter Manual Optional Charging...
  • Page 8 Description Optical Power Meter >2s PERM Save Unit 1-VFL connector( optional 2-OPM connector 3-LCD 4-OPM wavelength shift/WAVE ID key 5-VFL on/off key 6-Reference check/set key 7-Unit shift key 8-USB 9-Power/backlight key 10-Data save/recall key...
  • Page 9 Install the Batteries 1.Press and push up 2.Open the lid 3.Install the batteries 4.Push down and press...

  • Page 10: Power On/Off, Auto Power Off

    Power On/Off, Auto Power Off PERM PERM GLINT Optical Power Meter >2s PERM Save Unit Press the power key to turn on the device with auto power off. (After 10 minutes no key pressed, it will auto power off.) Press power key for 2 seconds when turn on the device, the auto power off will be cancelled, and the LCD PERM will show "...
  • Page 11 Backlight PERM GLINT Optical Power Meter >2s PERM >2s PERM Save Unit When the device power on, press the power key to turn on or turn off the backlight.

  • Page 12: Wavelength Select

    Wavelength Select PERM GLINT Optical Power Meter >2s PERM Save Unit When testing, you must select the right wavelength. Press the " " key for shifting the wavelength from: 850nm,1300nm,1310nm,1490nm,1550nm,1625nm.
  • Page 13 WAVE ID( optional PERM GLINT Optical Power Meter >2s PERM Save Unit Long press " " to turn on the WAVE ID and display " " at the same time. Long press again to exit the WAVE ID.
  • Page 14 Unit Select PERM GLINT Optical Power Meter >2s PERM Save Unit Unit Unit Press the " " key for shifting the unit from: dBm, mW/uW, after pressing " ", it shift to dB. After power off, the current unit will be saved mW/uW: 1mW=1000uW, 1uW=1000nW dBm: (dBm)=10*log(mW) dB: (dB)=REF-dBm...
  • Page 15 Reference PERM GLINT Optical Power Meter >2s PERM Save Unit Press " " key to check the reference value you set last time. And if keep pressing for 2 seconds, you can store the current dBm as a new reference value. Then it automatically shift to dB.

  • Page 16: Data Storage

    Data Storage PERM Save Save Optical Power Meter >2s PERM Save Unit Save hort press " " key to check the data storage SAVE Unit ress " " " " to change previous/next record. Long press " " key to save current value. SAVE...

  • Page 17: Visual Fault Locator (Optional)

    Visual Fault Locator (optional) PERM GLINT GLINT Optical Power Meter >2s PERM Save Unit The device can be built in an optional VFL module press the VFL key to shift the conditions: on-> glint->off...

  • Page 18: Battery Energy Detect

    Battery Energy Detect PERM GLINT Optical Power Meter >2s PERM Save Unit Sufficient power More power Less power Insufficient battery power...

  • Page 19: Battery Charge

    Battery Charge When you use rechargeable batteries and the meter indicates insufficient power, it should be turned off and charged. Long time undervoltage will cause the life of the battery to be shortened. When charging, the battery indication on LCD will flash. After charging fully, the indication will stop flashing and show full.
  • Page 20 Detailed Measuring range -50~+26dBm -70~+10dBm Calibrated 850nm,1300nm,1310nm,1490nm,1550nm,1625nm wavelengths +10~-60dBm(0.01dB) +26~-40dBm(0.01dB) Resolution -60~-70dBm(0.1dB) -40~-50dBm(0.1dB) Accuracy 0.2dB Linearity PD Type InGaAs FC(or SC) & 2.5mm UPP Connector Date storage VFL part Wavelength 650nm Output power 1mW or 10mW Connector 2.5mm UPP Auto power off Power supply AAX3 Battery life...
  • Page 21 USER'S GUIDE Optical Laser Source English...

  • Page 22: Precautions For Use

    WARNING Any undefined change or modification of this manual will deprive you of the right to operate the equipment. To reduce the risk of fire or electric shock, do not expose the equipment to rain or humidity. To prevent electric shock, please do not open the shell, and it must be repaired by qualified personnel.
  • Page 23 Standard Optical Laser Source >2s PERM Laser Host Manual Optional Charging...
  • Page 24 Description Optical Laser Source >2s PERM Laser 1-VFL connector( optional 2-Laser Source connector 3-LCD 4-Laser source wavelength shift key 5-VFL on/off key 6-Laser source modulation key 7-Laser source WAVE ID key 8-USB 9-Power/backlight key 10-Laser source on/off key...

  • Page 25: Install The Batteries

    Install the Batteries 1.Press and push up 2.Open the lid 4.Push down and press 3.Install the batteries...

  • Page 26: Power On/Off, Auto Power Off

    Power On/Off, Auto Power Off PERM PERM GLINT Optical Laser Source >2s PERM Laser Press the Power key to turn on the device with auto power off. (After 10 minutes no key pressed, it will auto power off.) Press power key for 2 seconds when turn on the device, the auto power off will be cancelled, and the LCD will show "PERM "...
  • Page 27 Backlight PERM GLINT Optical Laser Source >2s PERM >2s PERM Laser When the device power on, press the power key to turn on or turn off the backlight.
  • Page 28 Wave Select PERM GLINT Optical Laser Source >2s PERM Laser Press " " key to change the wavelength...

  • Page 29: Modulation Select

    Modulation Select 270Hz 1KHz 2KHz PERM GLINT Optical Laser Source >2s PERM Laser Press the " " key to shift from CW, 270Hz, 1KHz, 2KHz.
  • Page 30 WAVE ID PERM GLINT Optical Laser Source >2s PERM Laser Press " ID " to open the function of wavelength identification, on the LCD, it will displays "ID " , then the optical power meter which also has this function can identify the current wavelength in fiber, and the power meter will shift to the same wavelength automatically.
  • Page 31 Laser Source On/Off PERM GLINT Optical Laser Source >2s PERM Laser Laser Press the key to turn on/off the laser source output. " " on the LCD means laser output off...

  • Page 32: Visual Fault Locator (Optional)

    Visual Fault Locator (optional) PERM GLINT GLINT Optical Laser Source >2s PERM Laser The device can be built in an optional VFL module press the VFL key to shift the conditions: on-> glint->off.

  • Page 33: Battery Energy Detect

    Battery Energy Detect PERM GLINT Optical Laser Source >2s PERM Laser Sufficient power More power Less power Insufficient battery power...

  • Page 34: Battery Charge

    Battery Charge When you use rechargeable batteries and the meter indicates insufficient power, it should be turned off and charged. Long time undervoltage will cause the life of the battery to be shortened. When charging, the battery indication on LCD will flash. After charging fully, the indication will stop flashing and show full.
  • Page 35 Detailed 1310/1490/ Wavelength Customize 850/1300 1310/1550 1550 850nm>-10dBm Output power 1300nm,1310nm,1550nm,1490nm,1625nm>-6dBm 850nm,1300nm,1310nm,1550nm@FP Laser type 1490nm,1625nm@DFB Frequency 270Hz/1KHz/2KHz OP Adapter FC/PC or customize VFL part Wavelength 650nm Output power 1mW or 10mW Connector 2.5mm UPP Auto power off Power supply AAX3 Battery life >50H Operating temp...
  • Page 37 USER'S GUIDE Optical Multi Meter English...
  • Page 38 WARNING Any undefined change or modification of this manual will deprive you of the right to operate the equipment. To reduce the risk of fire or electric shock, do not expose the equipment to rain or humidity. To prevent electric shock, please do not open the shell, and it must be repaired by qualified personnel.
  • Page 39 Standard Optical Multi Meter >2s PERM Unit Save Laser Host FC/SC Adapter Manual Optional Charging...
  • Page 40 Description Optical Multi Meter >2s PERM Save Unit Laser 1-VFL connector 2-OPM connector 3-LCD 4-OPM wavelength shift/WAVE ID key 5-VFL on/off key 6-OPM unit shift key 7-OPM reference check/set key 8-Laser source modulation key 9-Laser source wavelength shift key 10-Laser source connector 11- USB 12-Power/backlight key 13-OPM data save/recall key...
  • Page 41 Install the Batteries 1.Press and push up 2.Open the lid 3.Install the batteries 4.Push down and press...
  • Page 42 Power On/Off, Auto Power Off PERM PERM GLINT 1310nm 1KHz Optical Multi Meter >2s PERM Save Unit Laser Press the Power key to turn on the device with auto power off. (After 10 minutes no key pressed, it will auto power off.) Press Power key for 2 seconds when turn on the device, the auto power off will be cancelled, and the LCD...
  • Page 43 Backlight PERM GLINT 1310nm 1KHz Optical Multi Meter >2s PERM >2s PERM Save Unit Laser When the device power on, press the power key to turn on or turn off the backlight.
  • Page 44 OPM Wavelength Select PERM GLINT 1310nm 1KHz Optical Multi Meter >2s PERM Save Unit Laser When testing, you must select the right wavelength. Press the " " key for shifting the wavelength from: 850nm,1300nm,1310nm,1490nm,1550nm,1625nm.
  • Page 45 OPM - WAVE ID(optional) PERM GLINT 1310nm 1KHz Optical Multi Meter >2s PERM Save Unit Laser Long press " " to turn on the WAVE ID and display " " at the same time. Long press again to exit the WAVE ID.
  • Page 46 OPM - Unit Select PERM GLINT 1310nm 1KHz Optical Multi Meter >2s PERM Save Unit Unit Laser Unit Press the " " key for shifting the unit from: dBm, mW/uW, after pressing " ", it shift to dB. After power off, the current unit will be saved mW/uW: 1mW=1000uW, 1uW=1000nW...
  • Page 47 OPM - Reference PERM GLINT 1310nm 1KHz Optical Multi Meter >2s PERM Save Unit Laser Press " "key to check the reference value you set last time. And if keep pressing for 2 seconds, you can store the current dBm as a new reference value. Then it automatically shift to dB.
  • Page 48 OPM - Data Storage PERM Save Save Optical Multi Meter >2s PERM Save Unit Save Laser hort press " " key to check the data storage SAVE Unit ress " " " " to change previous/next record. Long press " "...
  • Page 49 Laser Source On/Off PERM GLINT 1310nm 1KHz Optical Multi Meter >2s PERM Save Unit Laser Laser Press the key to turn on/off the laser source output.
  • Page 50 Laser Source - Wavelength Select / WAVE ID PERM 850nm 1300nm 1310nm 1490nm 1550nm 1625nm GLINT 1310nm 1KHz Optical Multi Meter >2s PERM Save Unit Laser Short press the " " key to shift the wavelength. Long press(>2s) the key to turn on WAVE ID function, "...
  • Page 51 Laser Source Modulation Select PERM 270Hz 1KHz GLINT 2KHz 1310nm 1KHz Optical Multi Meter >2s PERM Save Unit Laser Press the " " key to shift from CW, 270Hz, 1KHz, 2KHz.
  • Page 52 Visual Fault Locator (optional) PERM GLINT GLINT 1310nm 1KHz Optical Multi Meter >2s PERM Save Unit Laser The device can be built in an optional VFL module press the VFL key to shift the conditions: on-> glint->off.
  • Page 53 Battery Energy Detect PERM GLINT 1310nm Optical Multi Meter >2s PERM Save Unit Laser Sufficient power More power Less power Insufficient battery power...
  • Page 54 Battery Charge When you use rechargeable batteries and the meter indicates insufficient power, it should be turned off and charged. Long time undervoltage will cause the life of the battery to be shortened. When charging, the battery indication on LCD will flash. After charging fully, the indication will stop flashing and show full.
  • Page 55 Detailed OPM part Measuring range -70~+10dBm -50~+26dBm Calibrated 850nm,1300nm,1310nm,1490nm,1550nm,1625nm wavelengths +10~-60dBm(0.01dB) +26~-40dBm(0.01dB) Resolution -60~-70dBm(0.1dB) -40~-50dBm(0.1dB) Accuracy 0.2dB Linearity PD Type InGaAs FC(or SC) & 2.5mm UPP Connector Data Storage OLS part 1310/1490/ Wavelength Customize 850/1300 1310/1550 1550 850nm>-10dBm Output power 1300nm,1310nm,1550nm,1490nm,1625nm>-6dBm 850nm,1300nm,1310nm,1550nm@FP Laser type...
  • Page 56 Detailed Power supply AAX3 Battery life >50H Operating temp -10 ~+50 , 90%RH Storage temp -20 ~+60 , 90%RH 168mm*95mm*38mm Size 330g Weight...
  • Page 60 P/N40331 Rev.1005...
