Log Assembly: LOGS-ADI60
Model: ADI60
Carefully remove the logs from the packaging. CAUTION: Logs are fragile!
4
6
2
LOG #1 (SRV340-701):
tabs to either side of the burner. Pull the log forward until the log is stopped by the back edge of the burner. The log
should be centered.
2
LOG #2 (SRV340-702):
slot in the left end of the log slides into the vertical metal edge in front of the square cut out on the base pan.
1
5
1
Place log #1 in the back on the insert. Locate the legs of the log outside the 3/8"
Position log #2 by locating its slot over the tab on the front left of the burner. The
7
3
2
1
LOG PLACEMENT
INSTRUCTIONS
PILOT
BASE PAN
BURNER
1
345-935 6/02
Advertisement
Table of Contents
Related Manuals for Heatilator LOGS-ADI60
Summary of Contents for Heatilator LOGS-ADI60
- Page 1 Log Assembly: LOGS-ADI60 LOG PLACEMENT INSTRUCTIONS Model: ADI60 Carefully remove the logs from the packaging. CAUTION: Logs are fragile! PILOT BASE PAN BURNER LOG #1 (SRV340-701): Place log #1 in the back on the insert. Locate the legs of the log outside the 3/8"...
- Page 2 AREAS FOR LOG #4 PLACEMENT LOG #3 (SRV340-703): Position log #3 by locating its slot over the tab on the front right of the burner. Push the right side forward against the right grate tine. AREAS FOR LOG #5 PLACEMENT LOG #4 (SRV340-704): Place log #4 across log #1 and log #2 in the grooved out areas as shown.
- Page 3 LOG #6 (SRV340-705): Place log #6 across log #1 and log #5. The notch in the bottom of log #6 rests in the carved out section on top of log #5 and the left end of the log sits in the horizontal carved out section of log #1.
