Models:
WHB30, WHB33, WHB36, WHB42
WTB30, WTB33, WTB36, WTB42
These refractories are intended for use with the Novus NDV and NBV Series gas appliances. Check with your local build-
ing code agency before you begin installation to ensure compliance with local codes, including the need for permits and
follow-up inspections. If you encounter any problems regarding code approvals, or if you need clarifi cation of any of the
instructions contained here, contact your Hearth & Home Technologies Inc. dealer. For the dealer nearest you, please visit
www.heatilator.com
CAUTION
Sharp Edges
•
Wear protective gloves and safety
glasses during installation.
Note: An arrow ( ) found in the text signifi es change in content.
Heatilator • WHB/WTB Refractory • 4055-186 Rev C • 03/08
!
Hot Surfaces
•
Install this refractory only after the appliance
has cooled and the gas and electricity have
been shut off..
WHB
WTB
Installation
Instructions
WARNING
1
Advertisement
Table of Contents
Related Manuals for Heatilator WHB30
Summary of Contents for Heatilator WHB30
- Page 1 Models: WHB30, WHB33, WHB36, WHB42 WTB30, WTB33, WTB36, WTB42 These refractories are intended for use with the Novus NDV and NBV Series gas appliances. Check with your local build- ing code agency before you begin installation to ensure compliance with local codes, including the need for permits and follow-up inspections.
- Page 2 1. Shut off the electricity to the appliance and turn the gas shutoff valve to the closed position. See Figure 1. Remove the screen and glass from the appliance. Figure 1 - Gas Shutoff Valve 2. If installing this refractory into a B-Vent Appliance, please go to “To Convert Refractory Kit to Fit B-Vent Appliance”...
- Page 3 5. If lava rock has been placed in appliance, clean the rock away from the fi rebox sides to make room for the side refractory. See Figure 7. Figure 7 Move Lava Rock to Install Side Refractory 6. Carefully install a side refractory. See Figures 8 and 9. Figure 8 Position Side Refractory Figure 9...
- Page 4 12. Convert Refractory Kit to Fit B-Vent Appliance Locate the back refractory piece and lay the brick side down on a fl at surface. Locate the indicator marks on the back of the refractory piece. Lay a straight edge on the indicator marks and cut with a utility knife.
