DVBV4842-B-KIT, DVBV4236-B-KIT, DVBV3933-B-KIT, DVBV3630-B-KIT
Models: NDV3630I-B, NDV3630IL-B, NDV3933I-B, NDV3933IL-B,
NDV4236I-B, NDV4236IL-B, NDV4842I-B, NDV4842IL-B
NBV3630I-B, NBV3933I-B, NBV4236I-B, NBV4842I-B
CAUTION! Risk of Cuts, Abrasions or Flying Debris.
Wear protective gloves and safety glasses during instal-
lation. Sheet metal edges are sharp.
DANGER
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of
burns from the hot viewing glass is provided
with this appliance and shall be installed for
the protection of children and other at-risk
individuals.
Figure 1. Kit Contents
NDV/NBV Upgrade Kit
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
F F
Heatilator • NDV/NBV Upgrade Kit • 2382-955 • 1/16
KIT CONTENTS:
A. Embers
B. Flue Visor
C. Hearth Pan
D. False Back
E. Pilot Shield
F. Logs
A A
E E
C C
B B
D D
1
