REAL
9000 PLUS SERIES
®
SEE
QUICK REFERENCE GUIDE
Quick reference guide for use and settings. We reserve the right to change and update this manual at any time.
39-85 cm

BEFORE YOU BEGIN USING THE CHAIR

Inspect the chair for damage and notify the distributor at once if any damage is present.
Ensure all components are mounted and that they function as intended.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the REAL 9000 PLUS Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Mercado Medic REAL 9000 PLUS Series

Summary of Contents for Mercado Medic REAL 9000 PLUS Series

  • Page 1 REAL 9000 PLUS SERIES ® QUICK REFERENCE GUIDE Quick reference guide for use and settings. We reserve the right to change and update this manual at any time. 39-85 cm BEFORE YOU BEGIN USING THE CHAIR Inspect the chair for damage and notify the distributor at once if any damage is present. Ensure all components are mounted and that they function as intended.
  • Page 2 SAFETY Always mount the brake lever, as per the assembly instructions that accompany the chair, before the chair is used. Always apply the chair brakes before moving in and out of the chair. The lever can be moved from the right to the left side. If the chair is fitted with an electronic brake, then the switch for this is located under the armrest.
  • Page 3 ADJUSTING THE BACK The backrest can be set in a fixed angle or free floating. Adjust the height to ensure you have optimum support and a full range of motion, so you are able to do any desired activity. Choosing the correct backrest design and size, and adjusting it properly, are essential for chair functionality and comfort.
  • Page 4 SEAT TILT The seat tilt function should only be used when the chair is on a horizontal surface. The tilt range varies depending on the tilt mechanism installed and the chair settings. Max. 23° Max. 15° Gas tilt Manual tilt Electric tilt SEAT LIFT The seat lift and seat height depend on the lifting device that is mounted.
  • Page 5 FOOT RING AND FOOTREST A fold-up foot ring or footrest provides excellent support in an elevated sitting position. If the chair is equipped with support, it can be used to stand on when transferring out of the chair or during an activity. The footrest can be folded up under the front edge of the seat cushion for ease of movement and can easily be reached and folded out again by the user.
  • Page 6 ELECTRIC CHAIR FUNCTIONS If the chair is equipped with electric functions (lift, tilt, backrest), then one of the controls below will be mounted. The controls are movable. Do not place the control where it is likely to be damaged. The control is resistant to minor water spray but must not be immersed in water.
  • Page 7 SIZE GUIDE BACKREST SIZE TYPE ARTICLE No. 27 x 22 cm ErgoMedic BR107046 23 x 27 cm ErgoMedic BR105046 23 x 20 cm ErgoMedic BR108546 30 x 26 cm ErgoMedic BR106546 33 x 26 cm ErgoMedic BR106046 38 x 26 cm ErgoMedic BR105546 27 x 32 cm...
  • Page 8 The charging plug is removable. For complete operating and maintenance instructions, refer to the currently applicable user and maintenance manual. Mercado Medic AB Telephone & fax E-mail & website Tryffelslingan 14 Tel.
