REAL PLUS
REAL PLUS EL
GET ACQUAINTED WITH YOUR REAL 9000 PLUS
PRE-USE INSPECTION CHECKLIST
1. Adjust the armrests into a suitable height by loosening the knob on the side and make sure the lever controlling the
seat height is locked into its position.
2. Slide the backrest onto the designated pole and tighten the knob that allows you to alter the height of the backrest.
3. Insert the brake lever into the designated bracket (right or left side). This is not applicable for the electric brake.
4. Make sure all knobs and levers are secure and tightened before using the chair.
5. When getting in or out of the chair make sure that the brake is always applied.
6. To be able to use the electric functions; pull out the red transport safety pin, located in the charging socket
(only applicable for electric chairs).
7. Charge the chair according to attached directive.
INSTRUCTIONS FOR USE AND CARE
REAL 9000 PLUS/EL/ADULT/CHILD/MINI/COXIT
REAL PLUS CHILD/MINI
REAL PLUS CHILD/MINI EL
Mercado Medic AB
Tryffelslingan 14
181 57 Lidingö
Sweden
Telefon & Fax
Tel +46 8 555 143 00
Fax +46 8 555 143 99
Article No. 803410
Changed 130716
Valid from 070601
REAL PLUS COXIT
REAL PLUS COXIT EL
Email & Internet
Email
info@mercado.se
Internet www.mercado.se
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Mercado Medic REAL PLUS
Summary of Contents for Mercado Medic REAL PLUS
- Page 1 REAL PLUS REAL PLUS CHILD/MINI REAL PLUS COXIT REAL PLUS EL REAL PLUS CHILD/MINI EL REAL PLUS COXIT EL GET ACQUAINTED WITH YOUR REAL 9000 PLUS PRE-USE INSPECTION CHECKLIST 1. Adjust the armrests into a suitable height by loosening the knob on the side and make sure the lever controlling the seat height is locked into its position.
- Page 2 • Only electrical equipment from Mercado Medic AB is permitted for usage on the REAL PLUS EL. • Note! The electric functions of the REAL PLUS EL-chairs may only be used at a maximum of 10% of the time (max 6 min/h). If this limit is exceeded the chair can be damaged.
- Page 3 SEAT TILT (OPTIONAL) THERE ARE THREE ALTERNATIVE DESIGNS CONTROL FOR ADJUSTING THE TILT OF THE SEAT: 1. Seat tilt. Crank adjustment – turn the knob. Crank adjustment, Gas spring and Electric. The 2. Seat tilt. Gas spring – push the lever backward. lever for the gas spring is situated either at the back 3.
- Page 4 802289 when charging the chair. If another battery and the actuator. Replace the blown fuse with a new charger is desired, contact Mercado Medic AB for a 25A fuse. written approval. The battery should be charged regu- Pay attention to the following when handling larly;...
