Tools Required; Product Disassembly Process - HP t310 Quad Display Disassembly Instructions

Components, parts and materials containing
radioactive substances

2.0 Tools Required

List the type and size of the tools that would typically be used to disassemble the product to a point where components
and materials requiring selective treatment can be removed.
Tool Description
Phillips and flathead screwdrivers
Diagonal cutting plier
Nipper

3.0 Product Disassembly Process

3.1 List the basic steps that should typically be followed to remove components and materials requiring selective treatment:
1. Remove chassis labels, rubber and screws
2. Remove left plastic chassis
3. Remove rear and front plastic chassis
4. Remove light guide from the front chassis
5. Remove the screw on the bottom of metal chassis. Remove upper metal chassis
6. Separate PCBA board from the chassis using the screwdriver
7. Separate lower metal chassis from right plastic chassis using the screwdriver
8.
3.2 Optional Graphic. If the disassembly process is complex, insert a graphic illustration below to identify the items
contained in the product that require selective treatment (with descriptions and arrows identifying locations).
EL-MF877-00
Template Revision B
PSG instructions for this template are available at EL-MF877-01
0
Tool Size (if
applicable)
Page 2
