Summary of Contents for Kleenmaid KCGCT6011
- Page 1 Instructions for use and warranty details Gas Cooktop Model No.: KCGCT6011...
- Page 2 Once installation is complete, please read this instruction manual carefully and get to know the controls and the features of your new Kleenmaid appliance. These simple instructions will enable you to achieve excellent results from the very first time you use it.
- Page 3 Please read carefully If you are unsure of any of the information contained in these instructions, please contact our customer care centre. The manufacturer shall not be responsible for any damages to persons or property caused by incorrect installation or use of the appliance. be considered necessary or useful, also in the interests of the user, without jeopardising the main functional and safety features of the product itself.
-
Page 4: Table Of Contents
contents Preface Safety Warning Safety Instructions Installation Child and People Safety During Use Cleaning and Service Environmental Information Instructions for use and maintenance Description of the appliance How to Use the appliance Safety and Energy saving advice Cleaning and Maintenance Technical instructions Using instructions Positioning... -
Page 5: Safety Instructions
safety instructions Please take the time to read this User Manual before installing or using the appliance. If the appliance is sold or transferred to another person, ensure the booklet is passed on to the new user. accident caused by misuse in advance, and use the appliance more conveniently. Neglect of this mark may result in severe personal Danger/Warning injury or death. -
Page 6: Installation
installation Warning accordance with regulations in force gas and electrical supply complies and only used in a well ventilated with the type stated on the rating space. plate. 220V-240V marine craft or in caravans, it should not must be installed in such a way that be used as a space heater. -
Page 7: Child And People Safety
child and people safety Warning The appliance gets hot when it is in use. Children should be kept away until it has cooled. Caution from using the appliance safety without supervision or instruction by a responsible person to ensure that they can use the appliance safety. -
Page 8: During Use
during use Warning Burner panel is not designed to operate from food. an external timer or separate remote control system. comes The use of a gas cooking appliance results in the production of heat and moisture in contact with water. Do not operate the room in which it is installed. - Page 9 during use materials in a storage drawer aerosols may be affected by heat and should not stored above or below the near this appliance. appliance. this appliance while it is in operaiton. ‘ ’ position when not in use. Caution industrial purposes.
-
Page 10: Cleaning And Service
cleaning and service Warning cleaning agents. repaired or serviced by an authorised Service Engineer and only genuine approved spare parts should be used. Caution and cooled. clean the appliance. environmental information with due regard to safety and the environment. unusable by cutting off the cable. disposed with other household wastes at the end of its working life. -
Page 11: Description Of The Appliance
Dimension(W*D*H) ) Ignition device Gas Connection Electric supply Burner Feature ΣQn Continuous 220-240Vac, Stainless Triple-Crown (1), 590*510*90 Ignition KCGCT6011 1/2 thread 50Hz/60Hz, 8.3kW Steel Semi-rapid (2), Auxiliary (1) Type 0.6W how to use the appliance Black circle: gas off Large flame: maximum setting... - Page 12 how to use the appliance Automatic ignition with flame failure safety device The appliance is fitted with a flame failure safety device on each burner, which is designed to stop the flow of gas to the burner head in the event of the flame going out.
-
Page 13: Safety And Energy Saving Advice
safety and energy saving advice The diameter of the bottom of the pan should correspond to that of the burner. BURNERS of the 200mm 2 0mm burner. Rapid 200mm 240mm Semi-Rapid 160mm 120mm 160mm lid half off as this wastes energy. one side. -
Page 14: Cleaning And Maintenance
cleaning and maintenance completely Metal Brush Nylon Brush Soft cloth Detergent Neutral Detergent water. For stubbon soiling, soak beforehand. wrung-out the risk of corrosion. normal because of the high temperatures. Each time the appliance is used these parts should be cleaned with a product that is suitable for stainless steel. - Page 15 cleaning and maintenance from the top plate. detergent or washing up liquid cloth and wipe dry with a clean cloth. blocked. into 1 2 3 their respective recesses.
-
Page 16: Using Instructions
using instructions Warnings way that they do not touch any parts of the appliance which may out by the fitter after installation. The grease applied to the valve mechanism at the factory is designed to last the life of the hob. -
Page 17: Positioning
positioning 650mm 400mm 400mm FO 0813 The edges of the hob must be a minimum distance of 60 mm from a side or rear wall. The safety gap between the hob and the rangehood placed above must comply with the recommendations of the rangehood manufacturer. In case of no instructions, a minimum distance of 650mm (or other minimum distance as may be specified by AS/NZS 5601 and interpreted by a certified installer) should apply. -
Page 18: Installing The Appliance
installing the appliance Remove the pan supports, the burner lid and flame spreader and carefully turn the appliance upside down and place it on a cushioned mat. Take care that the Ignition devices and flame supervision devices are not damaged in this operation. -
Page 19: Gas Connection
gas connection Turn off power for safety and appliance protection. Close middle valve to prevent gas leakage. K eep away from inflammable materials around appliance. Before work, put on gloves. CAUTION Cool off the appliance for a while right after using appliance for your safety because you can get burned by high temperatures from the appliance. - Page 20 gas connection Statutory requirements This installation must conform with the following: ■ Manufacturer’s Installation instructions ■ Local Gas Fitting Regulations ■ Municipal Building Codes ■ Refer to AS/NZS 5601.1 for Gas Installations ■ S.A.A. Wiring Code ■ Local Electrical Regulations ■...
- Page 21 ■ Flexible Ho se: If installing with a hose a ssembly, it mu st comply with AS/NZS 1869, 10 m m ID, class B or D, no m o o re than 1 m m long and ins talled in accordance with AS/NZS 5601.1.
-
Page 22: Gas Specifition
Heat input and orifice size marked(mm) Gas type & Model No. pressure Wok burner Rapid burner Semi-rapid Auxiliary-rapid 6.3MJ/h 13.68MJ/h 3.6MJ/h Propand 1.04 0.72 0.53 2.75kPa KCGCT6011 Natural Gas 1.72 1.15 0.85 1.0kPa... -
Page 23: Electrical Connection
electrical connection ■ This appliance is designed to be connected to a 220-240V, 50/60Hz AC electricity supply. - Green/yellow = Earth - Blue = Neutral - Brown = Live ■ Switch 1 Switch 2 AC INPUT Switch 3 Switch 4 IGNITION When the power cord is damaged it must be replaced by the manufacturer, customer service agent or similarly qualified personnel. -
Page 24: Gas Ad Ustment J
gas ad ustment Remove the pan support, Burner lid and Flame spreader. Unscrew the injector using a 7mm box spanner and replace it with the stipulated injector for new gas supply. Carefully reassemble all the components. After injectors are replaced, it is advisable to tighten firmly. -
Page 25: Trouble Shooting
trouble shooting Repairs should be performed by a licensed technician only. Improper repair may result in considerable danger to you and others. No Spark. Check the electricity supply Not ignited The gas supply is closed. The gas supply is not completely Badly ignited open. - Page 26 The benefits given to you under this Kleenmaid Warranty are in addition to other rights and remedies to which you may be entitled under the Australian Consumer Law in relation to the Product to which this Kleenmaid Warranty relates. Subject to the conditions below, the Product is warranted by Kleenmaid and/or its agents to be free from defects in materials and workmanship for the Warranty Period for normal Domestic Use.
- Page 27 13. Kleenmaid accepts no liability for items that are lost, damaged, or stolen as a result of freight, transport or storage. If you are required to transport the Product to an authorised service centre, you must ensure that it is securely packed and insured.
- Page 28 Other products available in the Kleenmaid range of appliances Washing machines Clothes dryers Dishwashers Ovens Cooktops Steam ovens Microwave ovens Built in espresso coffee machines Rangehoods Freestanding ovens Refrigerators & Freezers Beverage Serving Cabinets Water Dispensers Vacuum Cleaners Compass Capital Services Pty Limited...
