- Page 1 Instructions for use and warranty details To register your warranty or make a warranty claim, scan this QR code: Gas Cooktop Model No.: GCTK9012...
- Page 2 Once installation is complete, please read this instruction manual carefully and get to know the controls and the features of your new Kleenmaid appliance. These simple instructions will enable you to achieve excellent results from the very first time you use it.
-
Page 3: Table Of Contents
contents Safety Warning Safety Instructions Installation Child and People Safety During Use Cleaning and Service Environmental Information Instructions for Use and Maintenance Description of the Appliance How to Use the Appliance Safety and Energy Saving Advice Cleaning and Maintenance Technical Instructions Installation Instructions Positioning Installing the Appliance... -
Page 4: Safety Instructions
Safety Instructions Please take the time to read this User Manual before installing or using the appliance. User Manual . If the appliance is sold or transferred to another person,ensure the manual is passed on to the new user. The latest version of this manual is available on our website. (See back page for details.) accident caused by misuse in advance, and use the appliance more conveniently. -
Page 5: Installation
Installation Warning This appliance shall be installed in Prior to installation,ensure that the accordance with regulations in force gas and electrical supply complies and only used in a well ventilated with the type stated on the rating space. plate. 220V-240V DO NOT USE THIS APPLIANCE The gas pipe and electrical cable AS A SPACE HEATER. -
Page 6: Child And People Safety
Child and People Safety Warning Do not allow children to play near or with the appliance. The appliance gets hot when it is in use. Children should be kept away until it has cooled. Caution from using the appliance safety without supervision or instruction by a responsible person to ensure that they can use the appliance safety. -
Page 7: During Use
During Use Warning Burner panel is not designed to operate from food. an external timer or separate remote control system. The use of a gas cooking appliance comes results in the production of heat and contact with water. Do not operate moisture in the room in which it is this appliance with wet hands. - Page 8 During Use materials in a storage drawer near this aerosols may be affected by heat and should not stored above or below the appliance. appliance. Danger of fire: Do not store items on the cooking surface. this appliance while it is in operaiton. ‘...
-
Page 9: Cleaning And Service
Cleaning and Service Warning repaired cleaning agents. or serviced by an authorised technician and only genuine approved spare parts should be used. Caution power supply and cooled. clean the appliance. Environmental Information with due regard to safety and the environment. unusable, by cutting off the cable. -
Page 10: Description Of The Appliance
Description of the Appliance Dimension Ignition Electric Burner Top Plate ΣQn (W*D*H) Connection supply device Feature Rapid (1), 41.2MJ/h/ Continuous 220-240Vac, G1/2 thread Semi-rapid(2), 900 10*99 Glass 11.4kW Ignition 50Hz-60Hz, Auxiliary (1), Type Triple-Crown(1) -
Page 11: How To Use The Appliance
Description of the Appliance ccessories Voltage regulator valve (1) Sponge (4) Bracket (4) Injector Screw (4) User Elbow (1) Auxiliary pan support (1) Manual (1) How to Use the Appliance Black circle: gas off Large flame: maximum setting Small flame: minimum setting The minimum setting is at the end of the anti-clockwise rotation of the control handle. - Page 12 How to Use the Appliance Automatic ignition with flame failure safety device The appliance is fitted with a flame failure safety device on each burner, which is designed to stop the flow of gas to the burner head in the event of the flame going out. To ignite a burner: Press in the control knob of the burner that you wish to light and turn it anti- clockwise to the maximum position.
-
Page 13: Safety And Energy Saving Advice
Safety and Energy Saving Advice - The diameter of the bottom of the pan should correspond to that of the burner. PANS BURNERS max. min. Triple-Crown 200mm 240mm of the Rapid 200mm 240mm burner. Semi-Rapid 160mm 180mm Auxiliary 120mm 160mm Do not use small diameter cookware on large Always use cookware that is burners. -
Page 14: Cleaning And Maintenance
Cleaning and Maintenance completely cool. power ing with is recommended Metal Brush Nylon Brush Soft cloth Acidic/Alkali Edible Oil Detergent Neutral Detergent Abrasive Thinner/Benzene water. For stubbon soiling, soak beforehand. rung-out the risk of corrosion. normal because of the high temperatures. Each time the appliance is used these parts should be cleaned with a product that is suitable for stainless steel. - Page 15 Cleaning and Maintenance caps burner heads from the top plate. detergent or washing up liquid. base safety device and igniter with a well wrung out cloth and wipe dry with a clean cloth. blocked. 1.Place the burner head ( 4 ) on to the burner base ( 5 ) so that the ignition safety device (6) and the igniter (7) extend through their respective holes in the burner head.
-
Page 16: Installation Instructions
NOTE: Before making preparations for or commencing installation, the installer should refer to the current online version of the User Manual, which is available on the Kleenmaid website (see back cover for details). be installed and connected in accordance with current... -
Page 17: Positioning
Positioning CLEARANCES REQUIRED WHEN FITTING THE HOB WITH A COOKER HOOD ABOVE 650mm 400mm 400mm FO 0813 This appliance is to be built into a kitchen unit or 600mm worktop,providing the following minium distances are allowed; The edges of the hob must be a minimum distance of 60 mm from a side or rear wall. -
Page 18: Installing The Appliance
Installing the Appliance Remove the pan supports, the burner caps and burner heads and carefully turn the appliance upside down and place it on a cushioned mat. Take care that the Ignition safety devices and igniters are not damaged in this operation. -
Page 19: Gas Connection
Gas Connection Turn off power for safety and appliance protection. Close main gas supply valve to prevent gas leakage. Keep away from inflammable materials around appliance. Before work, put on gloves. CAUTION Allow the appliance to cool after use for your safety. The high temperature reached by the appliance may cause burns. - Page 20 LpG ConVErSIon - rEGuLAtor Oncethesecheckshavebeencompleted,ifthe regulator still fails to perform in a satisfactory manner it should be replaced. 9. Onebyone,turntheknobstominimumandscrew this appliance is supplied set up for natural Gas in the bypass screw (accessible when the knob is usage. A conversion kit is included with the product for removed) until a small stable flame results.
- Page 21 Gas Connection Statutory requirements This installation must conform with the following: ■ Manufacturer’s Installation instructions ■ Local Gas Fitting Regulations ■ Municipal Building Codes ■ Refer to AS/NZS 5601.1 for Gas Installations ■ AS/NZS 3000 - Wiring Rules ■ Local Electrical Regulations ■...
- Page 22 Gas Connection ■ Flexible Hose: If installing with a hose assembly, it must comply with AS/NZS 1869,10mmID,class B or D,no more than 1. m long and installed in accordance with AS/NZS 5601.1. ■ Ensure that the hose does not contact the hot surfaces of the hotplate, oven, dishwasher or any other appliance that may be installed underneath or next to the hotplate.
-
Page 23: Gas Specification
Gas Specification Heat input and orifice size marked (mm) Gas type & pressure Wok burner Rapid burner Semi-rapid Auxiliary 10.8MJ/h 6.3MJ/h 4.3MJ/h 13.5MJ/h Universal 1.00 0.90 0.68 0.58 LP Gas 2.75kPa Natural Gas 1.72 1.50 1.15 0.93 1.0kPa... -
Page 24: Electrical Connection
Electrical Connection ■ This appliance is designed to be connected to a 220-240V, 50Hz-60Hz AC electricity supply. - Green/yellow = Earth - Blue = Neutral - Brown = Live It is necessary to allow disconnection of the appliance from the supply after installation. The disconnection can be achieved by having the plug accessible or by incorporating a switch in the fixed wiring in accordance with the wiring rules. -
Page 25: Gas Adjustment
Gas Adjustment Change the injector of the burners. Remove the pan support, burner cap and burner head. Unscrew the injector using a 7mm box spanner and replace it with the stipulated injector for new gas supply. Carefully reassemble all components. After the injectors are replaced, it is advisable to tighten them firmly in place. -
Page 26: Trouble Shooting
Trouble Shooting Repairs should be performed by a licensed technician only. Improper repair may result in considerable danger to you and others. Probable cause Solution Problem No Spark. Check the electricity supply. Will not ignite The burner is incorrectly assembled. Assemble the burner correctly. Open the gas supply The gas supply is closed. - Page 27 The benefits given to you under this Kleenmaid Warranty are in addition to other rights and remedies to which you may be entitled under the Australian Consumer Law in relation to the Product to which this Kleenmaid Warranty relates. Subject to the conditions below, the Product is warranted by Kleenmaid and/or its agents to be free from defects in materials and workmanship for the Warranty Period for normal Domestic Use.
- Page 28 13. Kleenmaid accepts no liability for items that are lost, damaged, or stolen as a result of freight, transport or storage. If you are required to transport the Product to an authorised service centre, you must ensure that it is securely packed and insured.
- Page 29 This page intentionally left blank.
- Page 30 This page intentionally left blank.
- Page 31 This page intentionally left blank.
- Page 32 Other products available in the Kleenmaid range of appliances Washing machines Clothes dryers Dishwashers Ovens Cooktops Steam ovens Microwave ovens Built in espresso coffee machines Rangehoods Freestanding ovens Refrigerators & Freezers Beverage Serving Cabinets Water Dispensers Vacuum Cleaners Compass Capital Services Pty Limited...
