U S E R ' S G U I D E
7920 SERIES 220 - 240V
Safety Instructions
Product View/Accessories
Assembly
Features / Operations
Routine Maintenance
5/5/06 11:25:01 AM
5/5/06 11:25:01 AM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7920 SERIES and is the answer not in the manual?

Questions and answers

Summary of Contents for Bissell 7920 SERIES

  • Page 1 Warranty ug310-5829_7920K_405.indd 1 ug310-5829_7920K_405.indd 1 OxyPro U S E R ’ S G U I D E 7920 SERIES 220 - 240V Safety Instructions Product View/Accessories Assembly 6-17 Features / Operations Routine Maintenance 18-20 Troubleshooting Consumer Services Replacement Parts ™...
  • Page 2 Thanks for buying a BISSELL OxyPro We’re glad you purchased a BISSELL OxyPro heated formula deep cleaner. Everything we know about floor care went into the design and construction of this complete, high-tech home cleaning system. Your OxyPro is well made, and we back it with a limited two-year warranty.
  • Page 3: Important Safety Instructions

    (ASTA approved to BS 1362) fuse is fitted in the carrier contained in the plug. Spares may be obtained from your BISSELL supplier. If for any reason the plug is cut off, it must be disposed of, as it is an electric shock hazard should it be inserted into a 13 amp socket.
  • Page 4 Belt Access Door PowerBrush Floor Nozzle Window ug310-5829_7920K_405.indd 4 ug310-5829_7920K_405.indd 4 Keep plenty of genuine BISSELL Advanced Deep Cleaning Formulas on hand so you can clean and protect whenever it fits your Trigger schedule. Always use genuine BISSELL Advanced Deep Cleaning Formulas. Non- BISSELL cleaning solutions may harm the machine and void the warranty.
  • Page 5: How To Use This Guide

    Familiarize yourself with the parts and where they go. Following this User’s Guide will greatly enhance your ability to get the most performance from your BISSELL OxyPro for many years. Your OxyPro comes in 3, easy to assemble components.
  • Page 6: Smartmix

    The BISSELL SmartClean The OxyPro is a home cleaning system that automatically mixes hand hot tap water with BISSELL Advanced Deep Cleaning Formula and heats the solution as it is applied to the carpet. The combination of heated cleaning solution, powered brush and suction provide a safe and effective method of cleaning.
  • Page 7 WARNING: To reduce the risk of fire, use only BISSELL Advanced Deep Cleaning Formula for full size machines in your OxyPro. Use of cleaning formulas that contain lemon or pine oil may damage this appliance and void the warranty.
  • Page 8: To Empty Tank-In-Tank

    Tank-in-Tank Our Tank-in-Tank system is designed with a Bladder inside for clean water. As you clean, the Bladder will empty. Dirty water collects in the tank outside the Bladder. Step on Handle Release to lay the machine handle down out of the way. Lift the Tank-in-Tank handle.
  • Page 9: The Flow Indicator

    Refill with clean hand hot tap water, following steps 5 through 9 on page 8, and refill the SmartMix Bottle with BISSELL Advanced Deep Cleaning Formula as necessary. When the cleaning job is complete, rinse out the Tank-in-Tank by rinsing clean water between the Bladder and Tank.
  • Page 10: Machine Preparation

    Set up the machine following instructions in the Features section on pages 6-9. Use only BISSELL Advanced Deep Cleaning Formula in the SmartMix Bottle when cleaning carpets, stairs or upholstery. Use clean water in the SmartMix Bottle for gentle cleaning or rinsing.
  • Page 11: Carpet Cleaning

    Water Rinse setting to give your carpeting a final rinse. This will ensure thorough removal of embedded dirt loosened by the BISSELL Advanced Deep Cleaning Formula. BISSELL Advanced Deep Cleaning Formulas contain an anti-resoiling agent that helps your carpets repel dirt and keeps them looking good longer.
  • Page 12: Stain Removal

    If no fuzzing occurs, continue cleaning in soiled area. Use your BISSELL Deep Cleaner as a precleaner. With one of the tools attached to the Flex Hose, set the ReadyTools Dial to Tools/PreTreat and the Smart Mix Dial to the High Traffic setting.
  • Page 13 Stain Removal In Between Deep Cleaning Do Not Delay! Failure to attend to an accident soon after it occurs may cause it to set and become permanent. ™ Use OxyKIC carpet spot & stain remover to permanently remove tough spots and stains like red wine, cola and fruit juice in between deep cleaning.
  • Page 14: When You're Done

    ™ Perfect Pass The Perfect Pass feature is designed to help you achieve the best cleaning results when deep cleaning. Apply smooth even strokes when deep cleaning your carpets. An upright deep cleaner should not be used at the same speed as an ordinary vacuum.
  • Page 15 Machine Preparation Set up the machine following instructions in the Features section on pages 6-9. Use only BISSELL Advanced Deep Cleaning Formula in SmartMix Bottle. Set the ReadyTools Dial to Tools/PreTreat. Note: Flow Indicator does not spin when set to Tools/PreTreat setting.
  • Page 16: Cleaning Bare Floors

    Caution: Do not use on hardwood floors. Use BISSELL Hard Floor Solutions in SmartMix Bottle. Vacuum or sweep thoroughly to pick up loose debris and pet hair. Remove easily moved furniture from the room (chairs, tables, etc).
  • Page 17 Set up machine following instructions in the Features section on pages 6-9. Be sure to thoroughly rinse out any remaining BISSELL Advanced Deep Cleaning Formula from the SmartMix Bottle to prevent slippery linoleum, vinyl, and tile floors. Use BISSELL Hard Floor Solutions in the SmartMix Bottle.
  • Page 18: Routine Maintenance

    Routine Maintenance Turn Power Switch OFF. Unplug power cord from the outlet and coil around Power Cord Quick Release. Remove and rinse tools in clean, running water. Dry and replace on tool caddy. Coil Flex Hose around storage brackets on Tool Caddy. Remove Tank-In-Tank, dispose of dirty water.
  • Page 19 Pump Belt Replacement Turn the Power Switch OFF and unplug from the wall outlet. Step on the Handle Release and recline the handle down onto floor (see illustration). Remove Tank-In-Tank and SmartMix Bottle. Set them aside (see illustration). Remove Belt Access Door located near the Floor Cleaning/ Tools switch by inserting a flat head screwdriver into the slot nearest to the handle and gently prying the access door off (see illustration).
  • Page 20 Assembly is now complete. If you have any questions, or are having trouble installing your Replacement Pump Belt, please call BISSELL Consumer Services in the UK at 0870-225-0109 or in Australia at 1-800-811-183. For all other countries call our USA Headquarters at 01-616-453-4451.
  • Page 21: Troubleshooting

    Turn the Power Switch ON. Remedies Refill Bladder with clean hand hot tap water. Fill with any BISSELL Advanced Deep Cleaning Formula for cleaning or water if rinsing. Clean out Flow Indicator Filter, page 18. Turn Power Switch OFF; remove & reseat tanks.
  • Page 22 If your BISSELL product should require service: In the UK and Australia, call BISSELL Consumer Services at the number below and we will give you the location of a BISSELL Authorized Service Center in your area. For all other countries contact your local in country distributor for questions, service, or repair.
  • Page 23 Replacement parts - BISSELL OxyPro Item Part No. 210-9213 603-0910 210-9148 210-1197 214-9131 214-9142 215-9155 015-9043 015-4439 015-9041 210-1785 210-1795 555-6503 210-4052 214-9874 215-0628 015-0621 213-3501 710E 720E 730E 740E 750E *Not all parts are included with every model. ug310-5829_7920K_405.indd 23 ug310-5829_7920K_405.indd 23...
  • Page 24: About Your Warranty

    Subject to the *EXCEPTIONS AND EXCLUSIONS identified below, BISSELL Homecare, Inc., will replace (with new or remanufactured components), at BISSELL’s option, free of charge from the date of purchase by the original purchaser, for two years any defective or malfunctioning part do to manufacturers defect.
