Bissell PROHEAT PET ADVANCED 1799 Series Quick Start Manual

QUICK START GUIDE
PROHEAT
Assembly Instructions
1. The only tool you will
need to assemble your
deep cleaner is a Phillips
screwdriver.
PARTS INCLUDED
1. Upper Handle
2. 4 Screws Taped to Upper Handle
3. Deep Cleaner Base
4. Tool Caddy
NOTE:
Not all accessories come with every model. Be sure to check the carton for additional tools.
160-8121 Rev 10/15
PET
®
2. First, slide the Upper 3. a.) From the flat side of
the Tool Caddy, feed the
Handle on to the base.
Power Cord through the
rounded-rectangle opening.
b.) Align the Tool Caddy with
the Upper Handle holes.
5. Hex Nuts
6. BISSELL Deep Cleaning formula
7. Nozzle Clean Out Tool
a.
b.
a.
4. a.) Insert 2 screws into
lower 2 holes above Lower
Hose Rack and turn until
tightened. b.) Place hex nuts
into back of Tool Caddy and
tighten bolts from the front.
Do not over tighten.
WARNING
Refer to the enclosed user guide for complete
instructions and important safety notices.
b.
5. Attach tools to the end
of the hose or front of the
upper handle. Wrap the
power cord and hose.
4.
1. 2.
3. 5.
1799 SERIES
7.
6.
