Front Runner KRTT001T Manual

Toyota tacoma slimline ii rack

Download this manual

READ ME FIRST:

Thank you for purchasing a Front Runner Slimline II Rack.

This Roof Rack consists of a kit that contains:

1.) A Slimline II Tray

2.) A mounting system specific to your vehicle

This document will help you fit the Slimeline II Tray to your specific vehicle.

IT IS CRITICAL THAT ALL FRONT RUNNER PRODUCTS BE PROPERLY AND SECURELY ASSEMBLED AND ATTACHED TO YOUR

VEHICLE. IMPROPER ATTACHMENT COULD RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY

INJURY OR DEATH TO YOU OR TO OTHERS. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT RUNNER

PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE

PRODUCTS FOR ADJUSTMENT, WEAR, AND DAMAGE. THEREFORE, YOU MUST READ AND UNDERSTAND ALL OF THE

INSTRUCTIONS AND CAUTIONS SUPPLIED WITH YOUR FRONT RUNNER PRODUCT PRIOR TO INSTALLATION OR USE. IF YOU DO

NOT UNDERSTAND ALL OF THE INSTRUCTIONS AND CAUTIONS, OR IF YOU HAVE NO MECHANICAL EXPERIENCE AND ARE NOT

THOROUGHLY FAMILIAR WITH THE INSTALLATION PROCEDURES, YOU SHOULD HAVE THE PRODUCT INSTALLED BY A

PROFESSIONAL INSTALLER OR OTHER QUALIFIED PERSONNEL.

REV_A00

TOYOTA TACOMA

SLIMLINE II RACK

(1165MM x 1358MM)

IMPORTANT WARNING!

KRTT001T

INSTALL TIME: 60 mins

Need help?

Do you have a question about the KRTT001T and is the answer not in the manual?

Page 1 VEHICLE. IMPROPER ATTACHMENT COULD RESULT IN AN AUTOMOBILE ACCIDENT, AND COULD CAUSE SERIOUS BODILY INJURY OR DEATH TO YOU OR TO OTHERS. YOU ARE RESPONSIBLE FOR ASSEMBLING AND SECURING ALL FRONT RUNNER PRODUCTS TO YOUR VEHICLE, CHECKING THE ATTACHMENTS PRIOR TO USE, AND PERIODICALLY INSPECTING THE PRODUCTS FOR ADJUSTMENT, WEAR, AND DAMAGE.
Page 2 GET ORGANIZED... Here is what you are looking at: You will need: a 13mm Flat and Socket Wrench Item # Quantity DESCRIPTION a 10mm Flat and Socket Wrench M6 NUT CAP Rag and some Denatured Alcohol M6x35 HEX BOLT a tube of Silicone M6x19x1 FLAT WASHER M8x16 HEX BOLT a Ladder...
Page 3 FIT the SIDE RAILS Using a flat screwdriver, starting from the front of the vehicle, lift and remove the two ditch moldings running along either side of the roof. Remove the tape covering the ten mounting points in the gutter (five on each side).
Page 4 FIT the SIDE RAILS Place the Side Rails onto the vehicle lining up the holes in the base of the Side Rails with the Aluminium Spacers . There is a left and a right hand Side Rail. The product sticker must go to the front outer side of the vehicle.
Page 5 You'll find a small amount of settling has happened. Go on many more adventures, periodically checking all nuts, bolts, screws and fittings. Front Runner can not recommend a maximum load carrying capacity. Please refer to your vehicle manufacturer's recommendations.
