3.9 Cabin and Baggage Compartment

CT Inspection and/or Required Maintenance Checklist
Fire extinguisher. Remove fire extinguisher (if applicable) and check
that expiry date is not exceeded. Replace if necessary.
Inspect
Upholstery.
cleanliness.
Safety belts. Inspect belts for wear, cuts, and broken stitching. Check
all buckles for proper locking and release. Check belt attachments to
structure.
Flight controls. Inspect for dents, nicks and scratches in push-pull
rods, play in rod end, security of rudder cable guide tubes to fuselage.
Lubricate rod end bearings.
Seats. Inspect seat structure for general condition, cracks, and
corrosion. Check seat controls for locking. Inspect cushions and
upholstery for condition.
Seat guides and stops. Inspect for cracks, wear of latching holes and
guides, and security of guides and stops.
Avionics. Check control knobs for operating. Check security of
indicators, radios, GPS display (if applicable), controls on side and
central panels, and markings legibility. Magnetic tools must not be
used during this procedure.
Instruments. Check security of instruments and markings legibility.
Magnetic tools must not be used during this procedure.
Placards. Inspect for presence and condition of all required interior
placards.
Instrument panels. Inspect for general condition, security of
attachment, and cleanliness. Magnetic tools must not be used during
this procedure.
Magnetic compass. Inspect for security and oil leakage. Inspect
compass correction card for presence and legibility of all headings.
Magnetic tools must not be used during this procedure.
Fuel valve. Inspect for operating and signs of fuel leakage.
Fuel Filter. Change fuel filter behind lower instrument panel at least
every 200 hrs.
ECS controls. Check cabin and carburetor heating, heating ducts and
side window vents for proper operation.
Instrument board inside and panels' backside. Remove all
instrument panels and inspect all lines, wires, control cables, hoses,
instruments, and so on, for chafing, any interference, and loose or
stressed connections. Inspect firewall structure for cracks, debonding,
and general condition.
Reinstall instrument panels. Check security of attachment and
condition.
Rudder pedals. Inspect for security, cracks, and play. Lubricate
pedals PVC supports.
Parking brake valve. Inspect for security of mounting and signs of
leakage.
Main Bulkhead. Inspect for cracks, dents, and debonding from the
fuselage.
AF 04800001
Maintenance and Inspection Procedures Manual
CT
Type:
for general condition,
Revision No. 3
CTLS
Series:
LSA
attachment, and
Page: 3-10
RLSA-M
Owner/Pilot
RLSA-M
RLSA-M
RLSA-M
RLSA-M
Owner/Pilot
Owner/Pilot
Owner/Pilot
Owner/Pilot
RLSA-M
RLSA-M
RLSA-M
Owner/Pilot
RLSA-M
Owner/Pilot
RLSA-M
RLSA-M
RLSA-M
Date: 14 Sep 2008
