Airplane Maintenance Manual (AMM)

CTLS-LSA with ROTAX 912 iS

Airplane Type

Airplane Model

Airplane Registration Number : _______________

Airplane Serial Number

Document Number

Date of Issue

This Manual is Approved on the Basis of Manufacturer Self Declaration

AND MAY NOT BE CITED, REPRODUCED, DISCLOSED OR DISTRIBUTED IN WHOLE OR IN PART

Template No.: PZ 0100 0034_00

Supplement S3 to the

THIS DOCUMENT IS THE PROPERTY OF FLIGHT DESIGN

WITHOUT PRIOR EXPRESS WRITTEN PERMISSION OF FLIGHT DESIGN

CTLS-LSA

: _______________

: AF 0480 0011

: 05-Aug-12
