Summary of Contents for FLIGHT DESIGN CTSW2006
- Page 1 Trim Tab Spring Modification CTSW2006 THIS DOCUMENT AND THE TECHNICAL DATA HEREON DISCLOSED ARE PROPRIETARY TO FLIGHT DESIGN AND SHALL NOT BE USED, RELEASED, OR DISCLOSED IN WHOLE OR IN PART WITHOUT EXPRESS WRITTEN PERMISSION FROM FLIGHT DESIGN...
- Page 2 CTSW 2006 Trim Tab Spring Modification Aircraft Type: LSA; LTF (BFU) FLIGHT DESIGN Page: 2 Table of Contents Table of Contents ....................2 Type of Maintenance .................... 3 Minimum Level of Certification Required .............. 3 General......................... 3 Used drawings ...................... 3 New parts ......................
- Page 3 Heavy Minimum Level of Certification Required Repairman, Light Sport Aircraft-Maintenance (RLSA-M). Task Specific: can be completed only by a responsible individual, which has received Flight Design Airplane Operation Training. General Set the plane on parking brake and ensure good access to the tail of the aircraft.
- Page 4 CTSW 2006 Trim Tab Spring Modification Aircraft Type: LSA; LTF (BFU) FLIGHT DESIGN Page: 4 Removing of old spring 1. Remove safety pin of the Angle Ball Joint M5 (pos 15) 2. Carefully disconnect head of Angle Ball Joint M5 (pos 15) from the ball head (screwed to the Rocker Arm pos.
- Page 5 CTSW 2006 Trim Tab Spring Modification Aircraft Type: LSA; LTF (BFU) FLIGHT DESIGN Page: 5 Install telescopic guide with new spring The telescopic guide consists of two tubes with washer welded to one end of each, that slide one in the other. The telescope supports the new spring from inside and is itself guided by the 5mm diameter rod (pos.
- Page 6 CTSW 2006 Trim Tab Spring Modification Aircraft Type: LSA; LTF (BFU) FLIGHT DESIGN Page: 6 Drawing 2 Check deflection angels of trim tab & stabilator following the maintenance manual of the aircraft and adjust deflections if necessary. Original Issue Date: 13.10.2006 Rev.
- Page 7 LSA; LTF (BFU) FLIGHT DESIGN Page: 7 Revisions The Revisions pages are updated by Flight Design each time revision is issued. They contain a list of all revisions made to the document since its original issue. Revision No. Date Released...
