Model: AC-309
Instruction Manual
Attention:
This appliance is not intended for use by persons (including Children)
with reduced physical, sensory or mental capabilities or lack of
experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not
play with the appliance.
Advertisement
Table of Contents
Related Manuals for Acorn AC-309
Summary of Contents for Acorn AC-309
- Page 1 Model: AC-309 Instruction Manual Attention: This appliance is not intended for use by persons (including Children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
-
Page 2: Table Of Contents
CONTENTS: 1. Safety Precaution ........... Page 2 2. Fan Structure Drawing ........... Page 3 3. Installation of Hanger Hook …........ Page 4 4. Installation of Down Rod / Hanger Ball ....Page 5 5. Installation of Fan Blades ........Page 6 6. -
Page 3: Safety Precaution
SAFETY PRECAUTION: IMPORTANT: PLEASE READ BEFORE INSTALLATION The installation work must be carried out by a qualified wiring installer. Turn off the Electrical Main Switch at the circuit breaker fuse box. Using power supply 220 – 240V/50HZ. When mounting the fan, to ensure the safety cable is loop across the ceiling mounting ‘J’... -
Page 4: Fan Structure Drawing
FAN STRUCTURE DRAWING:... -
Page 5: Installation Of Hanger Hook
INSTALLATION OF HANGER HOOK: 1) For Wood Ceiling: Install the hanger hook firmly onto the wood ceiling with two screws (fig 1). 2) For Concrete Ceiling: To use two expansion setscrew to install the hanger hook onto the concrete ceiling and fasten fig 1 firmly (fig 2). -
Page 6: Installation Of Down Rod / Hanger Ball
INSTALLATION OF DOWN ROD / HANGER BALL: 1) Remove the ‘R’ pin and Cross pin from the down rod (fig 3). 2) Install the canopy and housing cover through the down rod then thread the wires through the down rod, insert the down rod into the connector (fig 3). -
Page 7: Installation Of Fan Blades
INSTALLATION OF FAN BLADES: 1) Remove all the six screws from the rotating ring (fig 5). 2) Pointing the holes of blades to the rotation ring and fasten back all the six screws tightly (fig 5). fig 5 3) The finish product as (fig 6). fig 6 HANGING OF CEILING FAN: 1) Carefully... -
Page 8: Wiring Of Ceiling Fan
WIRING OF CEILING FAN: 1) Total four colors of wires connected from the top of the motor: * Red – Live wire for fan * Blue – Live wire for lightkit * Green – Ground wire * White – Neutral wire fig 8 2. -
Page 9: Installation Of Lightkit
Carefully lift the light cover by pushing up to light fixture and twist clockwise until its secured in position firmly (fig 11). fig 11 The finish product as (fig 12). NOTICE: Only the specified LED (Model: AC-309) fig 12 shall be used for lighting purposes. -
Page 10: Maintenance Tips
MAINTENANCE TIPS: 1. Because of the fan’s natural movement, some connections may be loose. To check the support connections, brackets and blades attachments 2 times a year. Make sure they are all secured (It is not necessary to dismantle the entire fan from ceiling). 2. -
Page 11: Troubleshooting
TROUBLESHOOTING: PLEASE CHECK THE FOLLOWING BEFORE LODGING A SERVICE REPORT PROBLEM REASON SOLUTION Fan not 1) Main cables not 1) Check mains & sub circuit moving connected. breakers or fuse. 2) Check the line wires. 2) Check the line wires connections to the fan &... -
Page 12: Performance Data
PERFORMANCE DATA: MS 1220:2010 a) Power Factor 0.992pF b) Rated speed in rpm 163 rpm c) Number of blades 2 pcs d) Type of regulator and Remote type regulator number of running positions e) Class of insulation Class B f) Type of bearings Deep groove sealed ball baring g) Rated air delivery 240m3/min...
