Model: AC-101
Instruction Manual
Attention:
This appliance is not intended for use by persons (including Children)
with reduced physical, sensory or mental capabilities or lack of
experience and knowledge unless they have been given supervision or
instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not
play with the appliance.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Acorn AC-101
Summary of Contents for Acorn AC-101
- Page 1 Model: AC-101 Instruction Manual Attention: This appliance is not intended for use by persons (including Children) with reduced physical, sensory or mental capabilities or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
- Page 2 CONTENTS: 1. Safety Precaution ........... Page 2 2. Fan Structure Drawing ........... Page 3 3. Installation of Hanger Bracket ....... Page 4 4. Installation of Downrod / Hanger Ball ....Page 4 5. Installation of Fan Blades ..………………………………... Page 5 6.
-
Page 3: Safety Precaution
SAFETY PRECAUTION: IMPORTANT: PLEASE READ BEFORE INSTALLATION The installation work must be carried out by a qualified wiring installer. Turn off the Electrical Main Switch at the circuit breaker fuse box. Using power supply 220 – 240V/50HZ. When mounting the fan, to ensure the safety cable is loop across the ceiling mounting ‘J’... -
Page 4: Fan Structure Drawing
FAN STRUCTURE DRAWING:... -
Page 5: Installation Of Hanger Bracket
INSTALLATION OF HANGER BRACKET: 1) To use Four Expansion Setscrew to install the hanger bracket firmly. (fig 1) fig 1 Concrete Ceiling 2) Install the ‘J’ hook onto the concrete ceiling and fasten firmly. Note the place of ‘J’ hook as (fig 2) fig 2 INSTALLATION OF DOWNROD / HANGER BALL:... -
Page 6: Installation Of Fan Blades
INSTALLATION OF FAN BLADES: 1) Remove the screws from the blade bracket. 2) Insert the blades into the motor housing, fasten onto the blade bracket with screws. (fig 5) 3) Ensure all blades are tighten firmly. fig 5 HANGING OF CEILING FAN: 1) Carefully lift assembly into hanger bracket... -
Page 7: Wiring Of Ceiling Fan
WIRING OF CEILING FAN: 1) Total three colors of wires connected from the top of the motor: * White – neutral wire * Green – Ground wire * Black – live wire for fan fig 8 2. Connect fan wires to ceiling wires: White to White, Black to Black, Green to Green. -
Page 8: Installation Of Separation Box
INSTALLATION OF SEPARATION BOX: 1) Remove the three screws of the separation cover. 2) Pointing the holes of the separation box to the three screw holes of the cover and tighten them (cover and box) firmly by the three screws. (fig10) fig 10... -
Page 9: Maintenance Tips
MAINTENANCE TIPS: 1. Because of the fan’s natural movement, some connections may be loose. To check the support connections, brackets and blades attachments 2 times a year. Make sure they are all secured (It is not necessary to dismantle the entire fan from ceiling). 2. - Page 10 MAINTENANCE TIPS: PLEASE CHECK THE FOLLOWING BEFORE LODGING A SERVICE REPORT PROBLEM REASON SOLUTION Fan not 1) Main cables not 1) Check mains & sub circuit moving connected. breakers or fuse. 2) Check the line wires. 2) Check the line wires connections to the fan &...
-
Page 11: Notes
NOTES: DRAWING SHOWING THE ASSEMBLY OF WIRES THROUGH FAN MOTOR SHAFT FOR DECORATIVE CEILING FAN...
