ALPHA BASE AND SUCTION CONNECTION DIAGRAMS
BASE VIEW FROM
ABOVE
ALL DIMENSIONS IN MM
REAR VIEW
1 1/2" STAINLESS STEEL FLEXIBLE
CONNECTOR (SUPPLIED AS STANDARD)
1 1/2" BSP TAPER FEMALE
THREADED STANDARD
TRIANGULAR SUCTION
WITH SUCTION HOLE
FOUR 15MM DIA.
MOUNTING HOLES
FLANGE ALIGNED
IN BASE
526
500
FRONT
SUCTION INLET
LOCATION
13
215
82
133
22MM DIA. ALTERNATIVE
CABLE ENTRY HOLE
76.5MM DIA.
ALTERNATIVE
SUCTION HOLE
SLOTTED TO
BOTTOM OF
BASE
S855/2
