Hytek ALPHA Series Technical Data Manual page 22

DRG. PART DESCRIPTION
REF
EXTERNAL COMPONENTS
1 LCD DISPLAY UNIT
(Above item
transformer board and fitting kit)
2 SIDE PANEL (UPPER CABINET)
3 UPPER DOOR
4 DOOR KEY
5 LOWER CABINET CAP
6 SIDE PANEL (LOWER CABINET)
7 LOWER DOOR
LOWER DOOR (FRONT NOZZLE
OPTION)*
8 MOUNTING BASE
9 LOCK (x 3)
10 SIDE ACCESS PANEL
11 NOZZLE HOLSTER WITH SWITCH
12 OUTLET ELBOW
13 SIDE PANEL WITH HOSE OUTLET
SIDE PANEL WITH HOSE OUTLET
(FRONT NOZZLE OPTION)
14 TOP CAP
INTERNAL COMPONENTS
15 DISPLAY COVER
16 MAINS/230VAC JUNCTION BOX
17 PULSER
18 4 PISTON METER (2 REV PER L)
AIR SEPARATOR OUTLET FLOAT
19
CHAMBER
20 MOTOR
21 FLEXIBLE SUCTION CONNECTOR
22 PULLEY
23 PUMP MOUNTING FRAME (x 2)
24 PULLEY BELT
25 PUMP UNIT (COMPLETE)
26 OUTLET CHECK VALVE
27 METER OUTLET PIPE
28 JUNCTION BOX
29 UPPER PANEL (x 2)
30 INLET FLANGE*
31 INLET GASKET*
32 RELAY (INSIDE JUNCTION BOX)*
33 PUMP MOUNTING PLATE*
34 CHECK VALVE*
35 BYPASS VALVE*
36 PUMP UNIT VANES* (X 6)
37 PUMP UNIT FILTER*
*Not shown on illustration
ALPHA PARTS LIST
includes LCD,
PART NO.
P50
ALP.DISP.PCB.3A
ALP.SPAN.E4
ALP.DOOR.E4
209.KEY
ALP.CAP.H4
ALP.SPAN.BL4
ALP.DOORH4
ALP.DOORHF4
ALP.BASE3
ALP.LOCK3
ALP.ACCPAN3
ALP.NOZBOOT.P
ELB.4FFCR
ALP.SPAN.H4
ALP.SPAN.HF4
ALP.CAP4
ALP.DISPCOV3A
ALP.JBOX.P
PULS.W
209A.METER.REP
MINIVENT
MOT.E75.ATEX
TTLB
PULL.2C
ALP.PFRAME3
VBLT.275
209A.PASSY.P
CHK.1P.DRILL
ALP.OUTPIPE.W
ALP.DBOX3
ALP.UPAN4
FLNG
GSK.TRI.P
ALP.RELAY
ALP.PPLATE3C
209EP.21
209EP.29
209EP.38
209EP.3
PART NO.
P70
ALP.DISP.PCB.3A
ALP.SPAN.E4
ALP.DOOR.E4
209.KEY
ALP.CAP.H4
ALP.SPAN.BL4
ALP.DOORH4
ALP.DOORHF4
ALP.BASE3
ALP.LOCK3
ALP.ACCPAN3
ALP.NOZBOOT.P
ELB.4FFCR
ALP.SPAN.H4
ALP.SPAN.HF4
ALP.CAP4
ALP.DISPCOV3A
ALP.JBOX.P
PULS.W
209A.METER.REP
MINIVENT
MOT.E75.ATEX
TTLB
PULL.25C
ALP.PFRAME3
VBLT.28
209A.PASSY.P
CHK.1P.DRILL
ALP.OUTPIPE.W
ALP.DBOX3
ALP.UPAN4
FLNG
GSK.TRI.P
ALP.RELAY
ALP.PPLATE3C
209EP.21
209EP.29
209EP.38
209EP.3
S855/2
