3. Mounting and installation
3.1 Basic remarks
Be careful to mount the sensor in an absolutely vibration-free area and that no parts within the detection
range are moving, because this might be detected as a material flow.
3.2 Installation of the sensor in general
The installation of the sensor depends on the conditions of the site.
When mounting the sensor, make sure that the sensor is fixed on a grounded plate before commissioning to
avoid damages due to electrostatic charge.
Fig. 2: Pin assignment
5
