Summary of Contents for SWR ENGINEERING SolidFlow
- Page 1 SolidFlow Monitoring of solids...
-
Page 2: Table Of Contents
Menu Structure of SolidFlow ........ -
Page 3: System Overview
Sensor and evaluation unit 2. Function SolidFlow is a measuring system especially developed for measuring the flow rate of conveyed solids in • metallic ducts. The SolidFlow sensor is based on the newest microwave technology. The sensor is usable in metal •... -
Page 4: Safety
Operating Instructions 3. Safety The measuring system SolidFlow was designed, built and tested to be safe and was shipped in safe conditions. Nevertheless persons or objects may be endangered by components of the system if these are operated in an inexpert manner. -
Page 5: Mounting And Installation
Operating Instructions Mounting and Installation 4.1 Delivery Range Evaluation unit in the housing • Weld on sensor accommodation • Sensor (union nut, distance washers, seal-ring for adjustment) • Operating instructions • C-Box (optional) • 4.2 Auxiliary Drill Ø 20 mm for steel •... - Page 6 Operating Instructions Weld the sensor accommodation on to the duct. • Drill the Ø 20 mm hole into the duct. Please use your own drill as there are different shafts available. • Take care that the hole is in line and rectangular to the surface to avoid trouble by inserting the sensor. Warning! After drilling you have to check, if there is a burr resulted at the drilling walls from the drilling.
- Page 7 Operating Instructions • Look at the POLARIZATION - label to adjust the sensor along to the duct, fig. 6b. Sensor accommodation O-ring-type sealing ring 36 x 3 Distance washer 1 mm Circlip for shafts 20 x 1.2 Distance washer 1 mm Union nut Fig.
-
Page 8: Mounting Of The Evaluation Unit
Operating Instructions 4.4 Mounting of the Evaluation Unit The whole electronic equipment can be installed at a maximum distance of 300 m from the sensor. • The housing is prepared for wall mounting. Fig. 7: Field housing evaluation unit. Sensor Evaluation Unit PG11 Fig. -
Page 9: Overview Of The Optional Use Of The C-Box
Operating Instructions 4.5 Overview of the Optional Use of the C-Box Sensor C-Box Evaluation Unit 2 m cable up to of the sensor at sufficient conductor manufactures firmly cross section The C-Box is an useful optional extension, if the distance between the sensor and the evaluation unit exceeds the given standard length of 2 meters. -
Page 10: Use In Ex Hazard Array
Operating Instructions 4.6 Use in Ex Hazard Array Marking DustEx: II 1/2D Ex tD IP 65 T84 °C Zone 20: 0 °C _ < T _ < 80 °C prozess Zone 21: -10 °C _ < T _ < 60 °C - Group of equipment 2 - Equipment category: 1/2 Waveguide window zone 20 / Housing zone 21... -
Page 11: Electrical Connection
Operating Instructions 5. Electrical Connection Fig. 9: Electrical connection Evaluation Unit Terminal No. Connection Connection of the Supply Voltage L / + 24 V Input Supply Voltage 230 V / 50 Hz, 110 V / 60 Hz (optional 24 V DC) N / 0 V Input Supply Voltage 230 V / 50 Hz, 110 V / 60 Hz (optional 24 V DC) Protected Earth... -
Page 12: Commissioning
In case that despite these steps a successful measurement is impossible, please contact SWR. • Commissioning of SolidFlow For start-up the sensor has to be calibrated and parameterized to each product, which will be measured. It is necessary to assign the mass flow to the display and initial value. The menu functions are mostly self-explaining. - Page 13 Operating Instructions Alarms entered by the user in menu 2. Analog Output is modified in menu 3 and can be adjusted to the individual requirements. (e. g. 0 - 20 mA) Auxiliary Points The linearisation can be examined by measuring the varying mass throughput. This should be weighed out in each single case for the improvement of the accuracy.
-
Page 14: Menu Structure Of Solidflow
Operating Instructions Following the menu parameters in detail: 7. Menu Structure of SolidFlow Measuring Range Tag No Adjust Material (10 Digits) Unit Adjust Text e. g. kg Time Scale Choose: h / min / s Decimal Point Choose Position of Dec. Point Beginning of Measuring Range Range 0 ... - Page 15 Operating Instructions Calibration Calibration Factor Range 0.01 ... 9.99 Calibration Filter Range 0.1 ... 999.9 s Number of Calibration Points Range 2 ... 20 Auxiliary Points Calibration Range 0.1 ... 999.9 s Range of Beginning - 4.4.1 Calibration Point 1 End of Measuring Value Meas.
-
Page 16: Menu Parameters
Operating Instructions 8. Menu Parameters: MEASURING RANGE 1.1 Tag No. Meas. Range £ Freely selectable symbols Tag No. of the measuring medium - or place, ¤ Material max. 10 digits. ¡ ¢ £ ¤ With select the letters or symbols with select place of the letter ¡... - Page 17 Operating Instructions 1.6 End of Measuring Range Meas. Range Enter the respective value of the measuring Set high range end. 10.0 kg/h With set the value to 1.0 to start enter the numbers of the measuring range, with transfer the entry and leave the menu level. 1.7 Filter Value Meas.
- Page 18 Operating Instructions 2.3 Alarm Dead Time Alarm Delay Threshold value how long the value must be over or under the limit until the alarm relay 1.0 s reacts. Range: 0.1 ... 99.9 s With leave the menu without any change, with transfer the entry and leave the menu level.
- Page 19 Operating Instructions 3.2 End of Range Analog Out Range set high Value for the output max. (Standard 20 mA) 20.0 mA Range 0 ... 22 mA With set the value to 0.0 to start enter the numbers of the measuring range, with transfer the entry and leave the menu level.
- Page 20 Operating Instructions 3.7 Trim 4 mA Analog Out Value of current min. Trim 4.0 mA Adjust to the external measuring system (if display differs). < < < > >> < < >> > With adjust fast, with < adjust slowly the current to 4 mA. With transfer the entry and leave the menu level, with leave the menu...
- Page 21 Operating Instructions 4.4 Calibration 4.4 Calibration £ £ ¤ With select according to your 4.4.1 Val. P1 0.00 ¤ significance, with leave the menu 4.4.2 Calibration P1 without any change, with transfer the 4.4.1 Val P2 1.58 entry and switch to a deeper menu level. 4.4.2 Calibration P2 4.4.1 Calibration Point 1 - Measuring Value Calibration...
- Page 22 Operating Instructions IMPULSE OUTPUT 5. Pulse out £ (For connection examples see paragraph 9.2) 5.1 Puls / Unit 10.00 ¤ Only necessary, if impulse output is required. £ ¤ With select according to your significance, with leave the menu without any change, with transfer the entry and switch to a deeper menu level.
- Page 23 Operating Instructions 6.2 Filter Digital In 1 Idle time after activation. Filter (Anti beat device for mechanical switches.) 1.0 s With set the value to 0.0 to start enter the numbers of the measuring range, with transfer the entry and leave the menu level. 6.3 Digital In 2 like Digital In 1 SYSTEM 7.
- Page 24 Operating Instructions 7.5 Backlight System Setting of durable lighting or the Backlight luminescence intensity. Zero switch on to permanent lighting. With set the value to 0 (complies in this menu to constant backlight) or enter the numbers of minutes for the delay of the backlight, with transfer the entry and leave the menu level.
-
Page 25: Connection Examples
Operating Instructions 9. Connection Examples 9.1 Digital Input ▼ = ((U - 1.6 V) / 20 mA) - 2 kW 9.2 Impulse Output Open Collector Open: 0 V Closed: Ub - 0.7 V Open: Ub Closed: 0.7 V Open Collector R = (Ub - 0.7 V)/l... -
Page 26: Additional Information For The Use Of Fme 300 Unit With A C3-Box
Operating Instructions 10. Additional Information for the Use of a FME 300 Unit with a C3-Box Connection C3-Box Evaluation Unit max. 300 m Each sensor is recognized by its own address. The address is signed on the sensor rating plate. - Page 27 Sensor 3 Programming In addition to the basic SolidFlow Start-up with one sensor it is necessary to switch on the sensors which should be used for the measurement (normally all sensors which are installed). As well every sensor has his own calibration-factor which can be used for adjusting the influence which each sensor gives to the measurement result (normally factor 1.0 for all sensors).
-
Page 28: Maintenance
Operating Instructions 11. Maintenance Warning! Danger of shock with opened housing! • Switch off the supply voltage for all maintenance or repair works on the measuring system. The tube • must not be in operation during a sensor exchange. Repair and maintenance work must be carried out by trained or expert personnel only. •... -
Page 29: Technical Data
Operating Instructions 14. Technical Data Sensor / Sensor Accommodation Housing: Steel St52, galvanised (stainless steel 1.4541 option) Protection category: IP 65, DustEx 20 or GasEx 1 (option) Operating temperature: Front end of sensor: -20 ... + 80 °C [-4 ... 176 °F] Optional: -20 ... -
Page 30: Quick Start Guide
SolidFlow Monitoring of solids Quick Start Guide... - Page 31 The menu is started by an invisible key in the bottom left hand corner of the touch-screen-panel. Now press approx. 5 seconds until the menu appears. If the temperature indication is activated, the button for the temperature indication is in the upper right corner, in this case must be changed into the temperature indication first, in order to be able to access the menu.
- Page 32 4.4.3 Calibration Point 2 - Measuring Value Measuring value in phys. units. Range: Measuring start - Measuring end 4.4.4 Calibration Point 2 - Raw Value Indicate the initial value to the value displayed. Once you set your calibration points, achieve a two runs of material and note the results. Weigh your material and calculate the difference.
