TVU networks TVU One Hardware User's Manual page 15

2
Product specifications
This section provides product specifications for the TVU One model TM1000 v1and TM1000 v2 transmitters.
Product specifications
Specification
Video Input formats
Audio input
Audio/Video encoding
and compression
Transmission
Dual encoders
Return video feed
Start-up time
Supported data connections
Glass-to-glass latency
Video recording
External interface connectors
Power source
Internal battery run time
DC input
Transmitter controls
TVU social support
Encoder hardware dimensions
Weight
Carrying case
Operating temperature
TVU Software version
TVU Networks® Corporation, © Copyright 2019
TVU One transmitter
HD/SD-SDI (BNC) input -1080i 59.94/50, 720p-59.94/50 480i-59.94, 576-50.
Up to 8 channels of embedded audio.
TVU264 or enhanced H265/HEVC
(The TVU One TM1000 v1 model does not support HEVC)
Inverse StatMux Plus (IS+)
Simultaneously live stream a transmission over IP while also encoding a completely
separate recording to the internal SSD that can be retrieved for future use.
TVU One feed or SDI input at TX; Requires hotspot
Less than 40 seconds
Simultaneously aggregates up to 12 data connections including WiFi and Ethernet.
System supports cellular 3G/4G/LTE modems, 2.4 GHz WiFi, 5 GHz WiFi, WiMax,
Ethernet, Microwave and KaBand, KuBand, BGAN Satellite connections.
0.5 seconds
Up to 7-hours of live recording
SDI, HDMI, USB, Ethernet, IFB
A single removable, rechargeable internal battery
120 minutes
Right angle Mini Jack DC input that connects to external
battery or supplied AC adapter.
External power adapter: 11-18V DC.
- One button start
- On-unit monitoring and management
- Remote monitoring and management using mobile smart device or laptop
Supports live streaming to Facebook Live. Also capable of capturing and
posting still images of TVU One's live stream to social media platforms
7.48 in. x 4.72 in. x 2.76 in.
(19 x 12 x 7 cm)
2.2 lbs (1 kg)
Belt-mount or shoulder bag carrying case options with hot swappable battery mount
32°F to 104°F (0°C to 40°C)
TVU6 v6.5
TVU One Hardware User Guide |
TVU One Hardware User Guide
Document part number: TVUOne UG Rev A EN 04-2019
11
