Graco Dura-Flo 600 Instructions - Parts Manual

Lowers
Hide thumbs Also See for Dura-Flo 600:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
Instructions - Parts
Dura-Flo
Stainless steel lowers with severe-duty rod and cylinder used for spray or transfer of
common industrial coatings and adhesives. For professional use only.
Dura-Flo 600 (145 cc) Lowers
Dura-Flo 750 (180 cc) Lowers
Dura-Flo 900 (220 cc) Lowers
Dura-Flo 1200 (290 cc) Lowers
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
See page 2 for model information, including maximum working pressure.
™
Lowers
311827G
EN
TI8343a

Advertisement

Table of Contents
loading

Related Manuals for Graco Dura-Flo 600

Summary of Contents for Graco Dura-Flo 600

  • Page 1 311827G Stainless steel lowers with severe-duty rod and cylinder used for spray or transfer of common industrial coatings and adhesives. For professional use only. Dura-Flo 600 (145 cc) Lowers Dura-Flo 750 (180 cc) Lowers Dura-Flo 900 (220 cc) Lowers Dura-Flo 1200 (290 cc) Lowers Important Safety Instructions Read all warnings and instructions in this manual.

  • Page 2: Table Of Contents

    Lowers ......11 Graco Information ......20 Dura-Flo 900 (220 cc) Lowers .

  • Page 3: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbol refers to procedure-specific risk. Refer back to these warnings. Additional, product-specific warnings may be found throughout the body of this manual where applicable.
  • Page 4 Warnings WARNING MOVING PARTS HAZARD Moving parts can pinch or amputate fingers and other body parts. • Keep clear of moving parts. • Do not operate equipment with protective guards or covers removed. • Pressurized equipment can start without warning. Before checking, moving, or servicing equipment, follow the Pressure Relief Procedure in this manual.

  • Page 5: Repair

    Repair Repair Pressure Relief Procedure Disassembly Lay out all the removed parts in sequence, to ease reas- sembly. Trapped pressure can cause the pump to cycle unex- Packing Repair Kits are available. For the best pectedly, which could result in serious injury from results, use all the new parts in the kit.
  • Page 6 (1) and cylinder (8), always use a rubber mallet to drive the rod out of the cylinder. Never use a hammer For Dura-Flo 600 and 750 Lowers: Turn the cyl- to drive the rod. inder (8) upside down and strike the top of the rod (1) on a plastic or wooden block until the •...
  • Page 7 Torque to 190-217 N•m (140-160 ft-lb). Detail Dura-Flo 600 and 750 Lowers 4518 TI8360a Dura-Flo 600 and 750: Torque to 258-285 N•m (190-210 ft-lb). Dura-Flo 900: Torque to 271-298 N•m (200-220 ft-lb). Dura-Flo 1200: Torque to 386-407 N•m (285-300 ft-lb). TI8361a TI8362a...

  • Page 8: Reassembly

    Repair Reassembly 8. Place the outlet housing (7) in a vise, see F . 1. Slide the rod (1) into the housing, then screw the cylinder (8) into the housing handtight. The threads 1. If it was necessary to remove the piston ball guide will engage easily until the seal (24*) contacts the (9) from the displacement rod (1), clean the threads sealing surface of the outlet housing.
  • Page 9 Repair Dura-Flo 600 and 750: Torque to 61-75 N•m (45-55 ft-lb). Dura-Flo 900 and 1200: Torque to 136-149 N•m (100-110 ft-lb). Torque to 325-353 N•m (240-260 ft-lb). Dura-Flo 600 and 750: Torque to 258-285 N•m (190-210 ft-lb). Dura-Flo 900: Torque to 271-298 N•m (200-220 ft-lb).

  • Page 10: Parts

    Parts Parts See the parts listings on pages 11 and 12. See Repair Kits, page 14 See Repair Kits, page 14 TI8342b 311827G...

  • Page 11: Dura-Flo 600 (145 Cc) And Dura-Flo 750 (180 Cc) Lowers

    Parts Dura-Flo 600 (145 cc) and Dura-Flo 750 (180 cc) Lowers See the parts drawing on page 10. Part numbers vary by lower. To find the part number used in your lower, read down the chart to find the desired ref. no., then read left to right to find the part number for your lower.

  • Page 12: Dura-Flo 900 (220 Cc) Lowers

    Parts Dura-Flo 900 (220 cc) Lowers See the parts drawing on page 10. Part numbers vary by lower. To find the part number used in your lower, read down the chart to find the desired ref. no., then read left to right to find the part number for your lower. Lower Part No.

  • Page 13: Dura-Flo 1200 (290 Cc) Lowers

    Parts Dura-Flo 1200 (290 cc) Lowers See the parts drawing on page 10. Part numbers vary by lower. To find the part number used in your lower, read down the chart to find the desired ref. no., then read left to right to find the part number for your lower. Lower Part No.

  • Page 14: Repair Kits

    109304 V-PACKING, throat; PTFE TI8389a1 TI8389a2 184304 V-PACKING, throat; leather 184224 GLAND, male, throat; stainless steel 237234 Repair Kit, Dura-Flo 600 Lowers 184225 GLAND, male, piston; stainless steel (standard for 247168, 236458) 109305 V-PACKING, piston; PTFE 184305 V-PACKING, piston; leather Ref.

  • Page 15: Ptfe Packings

    V-PACKING, throat; PTFE 184229 GLAND, male, throat; stainless steel TI8389a1 TI8389a2 184230 GLAND, male, piston; stainless steel 237236 Repair Kit, Dura-Flo 600 Lowers 109310 V-PACKING, piston; PTFE 184180 GLAND, female, piston; stainless steel Ref. Part No. Description 24F547 Repair Kit, Dura-Flo 1200 Lowers 184172 GLAND, female, throat;...

  • Page 16: Uhmwpe And Ptfe Packings

    109309 V-PACKING, throat; PTFE 109259 V-PACKING, throat; UHMWPE TI8389a1 TI8389a2 184229 GLAND, male, throat; stainless steel 237609 Repair Kit, Dura-Flo 600 Lowers 184230 GLAND, male, piston; stainless steel (standard for 241177, L145SS, L14BSS) 109310 V-PACKING, piston; PTFE Ref. 109260 V-PACKING, piston; UHMWPE Part No.

  • Page 17: Uhmwpe And Leather Packings

    109254 V-PACKING, throat; UHMWPE 184224 GLAND, male, throat; stainless steel TI8389a1 TI8389a2 184225 GLAND, male, piston; stainless steel 237238 Repair Kit, Dura-Flo 600 Lowers 184305 V-PACKING, piston; leather 109255 V-PACKING, piston; UHMWPE Ref. Part No. Description 184175 GLAND, female, piston; stainless steel 184172 GLAND, female, throat;...
  • Page 18 Repair Kits 311827G...

  • Page 19: Technical Data

    Maximum fluid working pressure ....See Graco Information 20, page 2. Lower effective area ......Dura-Flo 600 (145 cc): 6 cm (0.93 in.

  • Page 20: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
