HeartWare® Ventricular Assist System Patient Manual
Using the HeartWare® Shoulder Pack
To load the controller and batteries into the HeartWare® Shoulder Pack:
1.
Place the shoulder pack on a table or other
flat surface with the clear window facing
you. Open the flaps and zippers (see #1) to
access the equipment pockets. The Patient
ID Card may be placed in the clear pocket.
2. Open the snaps on the controller pocket
and insert the controller as shown in #2.
Fasten the snaps to secure the controller.

3. Insert the batteries into the two battery
pockets. The extra battery cable length can
be tucked into the compartment with the
battery. (see #3)
4. Close the flap and zip up both zippers.

5. Close the side flaps, leaving the driveline
between the top of the zipper and the side
flap. Fold the top closed (see #4).




Page 40
