FUNCTION DEFINE

■ Character Symbol
A b C d E F G H i J K L M
a b c d e f g h i j k l m
n o P q r S t U v W X y Z
n o p q r s t u v w x y z
1 2 3 4 5 6 7 8 9 0 / .
1 2 3 4 5 6 7 8 9 0 / .
■ Input Range & Mode

Input Range
The meter has been designed very wide input
range from 0.01Hz~100.00KHz(Option:
0.01Hz~140.00KHz) that can cover almost any
application for frequency measuring. User doesn't
need to specify the input range.
Especially, they do not set the scale to relate
the input range. Users are just set the measuring
type(pVtyp) in [input group]. The display of
meter will show the value that user wants to show
such as RPM, Linearly Line Speed or Frequency.
Please refer to the description of Display Function.

Input mode Switchable
NPN / PNP / Voltage Pulse / Mech. Contact
and amplitude can be switched by switches on
rear of meter.
21 22 23 24 25 26 27 28 29 30 31
Dip
11 12 13 14 15 3 4 5
Switch
*The excitation supply of sensor can not be
changed. Please specify in ordering code.
■

Display Functions


Multi-Display function
Programmable: lNspd /
/
The meter has desgined for mult-purpose. User
can set the display purpose in [pVtyp] of [input
group] such as lNspd(Linearly Line Speed),
rpm(RPM), rps(RPS),
(kHz) that the meter will display according to the
input and setting to calculate. The meter will show
the relation parameters as below,
●
lNspd: Pulse/rotation( ppr), Engineer
Units( m/mn / cm/mn / yd/mn / ft/mn),
Diameter of rotordiamt)
●
rpm / rps: Pulse/rotation(
2 / 39
32 33 34
DIP SW 1 2 3
ON
NPN
ON
PNP
ON
M.C.
5V
P
ON
6 7 8 9 10
12V
P
24V
P
D-S is on when it is in down site.
rpm / rps /
khz
hz(Hz),
ppr)
CS2 SERIES –OPERATION

Factor function:
Settable range: 0.001~9.999
Display = Value of math with setting x Factor
The display can be proportioned by factor.
The typical application is compensation for gear
ratio.

Auto-range function:
Programmable:
●
auto(Auto range): The decimal point will be auto
changed according to the input frequency so that
keep the display in the highest resolution.
Ex.: RPM of Motor: 7200RPM，Encoder: 1000ppr
The meter setting
[pVtyp]:
[range]: auto
(7200rpm x 1000ppr) / 60 = 120.000kHz
Frequency range is from 0~120.000kHz
The table is between input and display as below,
Freq. Input
0Hz
166.65Hz
1666.5Hz
16.665kHz
16.666kHz
120kHz
The input goes down to
4 5
166.65Hz
ON
●
semi(Semi-Auto range): The decimal point will
be auto changed according to the input frequency
ON
to keep the display in the highest resolution, but it
must be under setting position of decimal point.
It's possible to show " ovfl(overflow)", if the input
frequency is too high to makeover the display
range.
Ex.: RPM of Motor: 7200RPM，Encoder: 1000ppr
hz
as same as above,
The meter setting
[pVtyp]:
[range]: semi；[
The table is between input and display as below,
khz
Freq. Input
0Hz
166.65Hz
1666.5Hz
16.665kHz
16.666kHz
120kHz
The input goes down to
16.665kHz
In the case of input, the [
to display full range of RPM and to get higher
resolution in lower RPM.
MANUAL(EN)-2017-02-09-一般
auto / semi / manul
rpm, [ ppr]: 1000,
Display
0.0000 RPM
9.9999 RPM
99.999 RPM (Auto change)
999.99 RPM (Auto change)
1000.0 RPM (Auto change)
7200.0 RPM
9.9999 RPM (Auto change)
rpm；[ ppr] : 1000
dp] : 0.00
Display
0.0000 RPM
9.9999 RPM (Auto change)
99.999 RPM (Auto change)
999.99 RPM (Auto change)
ovfl RPM
ovfl RPM
999.99 RPM (Auto change)
dp] should set
Auto change to
keep highest
resolution
Auto change to
keep highest
resolution
0.0
