Operating Steps; User Level; Function Description - ADTEK CS2-RL Operation Manual

■

Operating Steps:

User Level

■
INDEX
POWER
ON
cs@rl
100)0
no
Next Page
18 / 39

FUNCTION DESCRIPTION

Please check the specification and
wiring diagrams firstly.
Self-diagnosis (LED All bright)
Model
cs@rl: RPM/Linearlly Line Speed/ Frequency
cs@f: Frequency
Firmware version
Measuring Page
for 1 second to access [User
Press
Level]
This page will show out, when
[dsply](step A-7) function has not set
pv .
to be
pv(Pv): Present Value;
ry!sp(rY1.SP):Relay 1 Set-point
◘
Please confirm the energized mode of
relay 1 before setting.
ry@sp(rY2.SP):Relay 2 Set-point
◘
Please confirm the energized mode of
relay 2 before setting.
ry#sp(rY3.SP):Relay 3 Set-point
◘
Please confirm the energized mode of
relay 3 before setting.
ry$sp(rY4.SP):Relay 4 Set-point
◘
Please confirm the energized mode of
relay 4 before setting.
rYrst(rY.rSt): Reset for energized latch
of Relay;
If the [ry_.md](step B-3/7/11/15) set to be
hIhld or lOhld, and the present
value(PV) reach to the condition of relay
energising, the relay will be energized and
latching.
At mean time, user can reset the relay
latching in here.
CS2 SERIES –OPERATION
PARAMETERS & SETTING SET
Press
to Measuring Page
Settable range: 0~99999
Shift Up
Settable range: 0~99999
Shift Up
Settable range: 0~99999
Shift Up
Settable range: 0~99999
Shift Up
Programmable:
yes(Yes): reset the relay
latching.
no(No): abort to reset the
relay latching.
& Selection
◘
Be careful, the relay has been
energizing and latching, if the
PV still reach to the condition
of relay energized, enven
user had set here to reset the
relay latching.
